6.3. Advanced Keypad Operation Short Cuts

Function
Fast Selection of
Parameter Groups
Note : Parameter Group
Access must be enabled
P1-14 = 101
Select lowest Group
Parameter
Set Parameter to
minimum value
Adjusting individual digits
within a parameter value

6.4. Drive Operating Displays

Display Status
    Drive mains power applied, but no Enable or Run signal applied
      Motor Autotune in progress.
 x.x Drive running, display shows output frequency (Hz)
 x.x Drive running, display shows motor current (Amps)
 x.x Drive Running, display shows motor power (kW)
 x.x Drive Running, display shows customer selected units, see
parameters P2-21 and P2-22
      Drive mains power not present, external 24 Volt control power supply present only
      Output power hardware inhibited, hardware enable circuit open. External links are required to the STO inputs (terminals
12 and 13) as shown in section 4.7.2 Connection Diagram
    
Parameters reset to factory default settings
     Parameters reset to User default settings
For drive fault code displays, refer to section 13.1 on page 51.
