11.3.4. BACNet MSTP commissioning
In order to connect the drive and operate on a BACNet MSTP network, the following procedure should be used.
1. Set P1-14 = 101 to allow access to the extended parameters
2. On each drive, set a unique MAC ID in parameter P5-01
3. Set the required MSTP baudrate in P5-03
4. Select the required data format in P5-04
5. Define a unique BACNet Device Instance ID for each drive using parameters P5-09 and P5-10
6. Select control from BACNet connection by setting P1-12 = 6
11.3.5. Object Dictionary
Binary Value Object:
Instance ID Object Name
BV0 Run/Stop State
BV1 Trip State
BV2 Hand Mode
BV3 Inhibit Mode
BV4 Mains Loss
BV5 Fire Mode
BV6 Enable State
BV7 External 24V Mode
BV8 Maintenance Due
BV9 Clean Mode
BV10 Terminal Mode
BV11 Bypass Mode
BV12 Digital Input 1
BV13 Digital Input 2
BV14 Digital Input 3
BV15 Digital Input 4
BV16 Digital Input 5
BV17 Digital Input 6
BV18 Digital Input 7
BV19 Digital Input 8
BV20 Relay Output 1
BV21 Relay Output 2
BV22 Relay Output 3
BV23 Relay Output 4
BV24 Relay Output 5
BV25 Run/Stop CMD
BV26 Fast Stop
BV27 Trip Reset
BV28 Coast Stop
BV29* Relay 1 CMD
BV30* Relay 2 CMD
BV31* Relay 3 CMD
BV32* Relay 4 CMD
BV33* Relay 5 CMD
* This function only works if the relay output can be controlled by user value (Refer to the Optidrive Eco Parameter List for further details)
44
Optidrive Eco User Guide Revision 2.01
Binary Value Objects Table
Access
R This object indicates drive run status
R This object indicates if drive is tripped
R This object indicates if drive is in hand or auto mode
R This object indicates drive is hardware inhibit
R This object indicates if mains loss happened
R This object indicates drive is in fire mode
R This object indicates if drive has enable signal
R This object indicates drive is in external 24V mode
R This object indicates if maintenance service is due
R This object indicates if pump clean function is on
R This object indicates if drive is in terminal control mode
R This object indicate if drive is in bypass mode
R Status of digital input 1
R Status of digital input 2
R Status of digital input 3
R Status of digital input 4
R Status of digital input 5
R Status of digital input 6
R Status of digital input 7
R Status of digital input 8
R Status of relay output 1
R Status of relay output 2
R Status of relay output 3
R Status of relay output 4
R Status of relay output 5
C Drive run command object
C Fast stop enable object
C Trip reset object (rising edge active)
C Cost stop enable object (overrides fast stop)
C User specified relay output 1 status.
C User specified relay output 2 status.
C User specified relay output 3 status.
C User specified relay output 4 status.
C User specified relay output 5 status.
Description Active/Inactive Text
RUN/STOP
TRIP/OK
HAND/AUTO
INHIBIT/OK
YES/NO
ON/OFF
YES/NO
YES/NO
YES/NO
ON/OFF
ON/OFF
ON/OFF
ON/OFF
ON/OFF
ON/OFF
ON/OFF
ON/OFF
ON/OFF
ON/OFF
ON/OFF
CLOSED/OPEN
CLOSED/OPEN
CLOSED/OPEN
CLOSED/OPEN
CLOSED/OPEN
RUN/STOP
ON/OFF
ON/OFF
ON/OFF
CLOSED/OPEN
CLOSED/OPEN
CLOSED/OPEN
CLOSED/OPEN
CLOSED/OPEN
