2- Specifications and Requirements
Power Requirements
24 Vdc ± 10%.
2.5 Amps max. @ 24 Vdc @ 25% print ratio.
Test Standards
BS EN 61000-6-3:2007+A1:2011
61000-6-2
ANSI C63.4-2014 or 2009
FCC Part 15 Subpart B – CLASS A
Canada ICES-003 issue 6 – CLASS A
EN55022:201+AC:2011 – CLASS A
EN 61000-3-2:2014
EN 61000-3-3:2013 – Clause 5
EN55024 :2010
IEC 61000-4-2:2008 – Level 3 Class A
IEC 61000-4-3:2006+A1:2007+A2:2010
– Level 2 Class A
IEC 61000-4-4:2012 – Level 2 Class A
IEC 61000-4-5:2014 – Level 2 Class A
IEC 61000-4-6:2013 – Level 2 Class A
IEC 61000-4-8:2009 - Level 1 Class A
IEC 61000-4-11:2004
Acoustic Noise:
Less than 65 decibels max. while printing a 30/30 format. (measured in 10 positions @ operator
level with distance of 1 meter, per ISO 779).
Mechanism Characteristics
Drawer Slide Force:
Opening Distance:
Drawer Holding Force:
Mechanism Operating Angle:
Page 14
TBD lbs. max.
190mm (7.5") (approximate ).
4.5 lbs. (out of detents).
Horizontal to 45º inclination (ticket exit slot up).
August 2018
Epic Edge OEM Integration Manual
100-14444 Rev B
