9-Transact Template Language
Defining a Region
Below is an example of the commands used to define Region 2 - Validation Number.
Note that the template consists of a series low level printer control codes.
User Defined Region 2
Command Sequence
[GS] M<2>
[ESC]t<0>
[ESC]!<2>
[GS]!<0>
[ESC]G<1>
[GS]$<0><0>
[GS]F<x80><0><100><1><244>
[GS] M<2>
100-14444 Rev B
Table 5 Example - User Defined Region 2
Setup for validation field
Explanation
Begin recording Region 2 commands
Set Print Direction in page mode = A
Select print mode = 13x24, 14 CPI
Select character size = 1W/1H
Set emphasized print
Set absolute vertical position = 0
Set field (Validation Number field, Left, 100,
500)
Follow with dynamic text, terminated with [CR]
End recording Region 2 commands
August 2018
Epic Edge™ OEM Integration Manual
Page 159
