8-Printer Commands
GS * – Landscape Mode Graphics
Description
Prints a graphic image (in landscape mode only).
Expression
ASCII [GS] * n1 n2 t h w d1...dm
Hexadecimal 1DH 2AH n1 n2 t h w d1...dm
Decimal <29> <42> <n1> <n2> <t> <h> <w> <d1...dm>
Parameters n1 = most significant byte of left offset
n2 = least significant byte of left offset
t = offset from top (in millimeters)
h = height of graphic (in millimeters)
w = width of graphic (in dots)
d1 = first data byte
dm = last data byte (h * w)
