Directed DS4+ Installation Manual page 12

Module
Conn./Pin Color Description
H2/17 Black/White (-) E-Brake Input
H2/18 Orange/Black (+) Instant Alarm Input
H2/19 Blue (-) Trunk Input
H2/20 Green (-) Door Input
H2/21 Gray (-) Hood Switch Input [1]
H2/22 Violet/White (AC) Tach Input
Main harness, 12-pin black connector (H3)
Module
Conn./Pin Color Description
H3/1 Blue/White Relay N.C. Immo. Data Interrupt (conn. side)
[4]
H3/2 Blue/Red Relay N.O. No Connection
H3/3 Blue Relay COM Immo. Data Interrupt (vehicle) [4]
H3/4 White/Brown Relay N.C. No Connection
H3/5 White Relay COM No Connection
H3/6 Red (+) 12 Volt Input
H3/7 Lt. Green/Red Relay N.O. No Connection
H3/8 Lt. Green Relay COM Lock Detection Interrupt (vehicle
side)
H3/9 Lt. Green/White Relay N.C. N Lock Detection Interrupt (conn.
side)
H3/10 Black (-) Ground
H3/11 White Relay COM No Connection
H3/12 Red (+) 12 Volt Input
Relay harness, 10-pin white connector (H4)
Module
Conn./Pin Color Description
H4/1 N/A No Connection
H4/2 Red/Black (+) 12 Volt Input
H4/3 Pink/Black Flex Relay (pin 87a)
H4/4 Pink/White (+) Flex Relay Output
H4/5 Red (+) 12 Volt Input
H4/6 Green Starter Input (conn. side) [3]
H4/7 Violet (+) Starter Output (vehicle side) [3]
12 933.HKHT1 3.20.193.1 2012 Hyundai Accent
© 2019-03-20 Directed. All rights reserved.
Connects To
Wire Location
No Connection
No Connection
No Connection
No Connection
No Connection
Connects To
Wire Location
left of dash fuse box, black 21 pin plug, pin 11
No Connection
left of dash fuse box, black 21 pin plug, pin 11
No Connection
No Connection
ignition switch, black 6 pin plug, pin 1
No Connection
With OEM Alarm.
driver kick, white 39 pin plug, pin 38
With OEM Alarm.
driver kick, white 39 pin plug, pin 38
No Connection
ignition switch, black 6 pin plug, pin 1
Connects To
Wire Location
No Connection
ignition switch, black 6 pin plug, pin 1
No Connection
No Connection
ignition switch, black 6 pin plug, pin 1
ignition switch, black 6 pin plug, pin 3
Connection required for Starter Disable ONLY.
ignition switch, black 6 pin plug, pin 3
(+/-) Wire Color Connection
(+/-) Wire Color Connection
data blue/orange (EMS COM) Remote Start
Only
data blue/orange (EMS COM) Remote Start
Only
+ green (50A) Mandatory
open blue/black Mandatory
open blue/black Mandatory
(chassis ground) Mandatory
+ green (50A) Mandatory
(+/-) Wire Color Connection
+ green (50A) Remote Start
Only
+ green (50A) Remote Start
Only
+ white Mandatory
+ white Mandatory
