Pre-installation and application warnings

Firmware notes: This section highlights important information for this specific firmware and will assist in
pricing accordingly, as well as bringing awareness to any operational or vehicle limitations.
T-Harness
compatible
The optional Plug & Play THHYN3 T-Harness is sold separately.
Š
The OBDII Diagnostic Connector features will remain the same even when the T-Harness is installed.
Š
Important! If your vehicle is NOT equipped with transponder immobilizer AND also does NOT use CAN connections,
Š
please flash your module with analog firmware.
All connectors are displayed from the wire side (unless specified otherwise).
Š
It is important to check that the fuses are positioned correctly in the module. Proper fuse positioning is displayed on each
Š
wiring diagram.
Refer to the "Vehicle connections" following the installation diagram.
Š
General notes: This section highlights important information for this specific firmware.
The installation of an aftermarket hood pin is ONLY required on vehicles that are NOT equipped with a factory hood pin.
[1]
The siren is ONLY required when enabling the security features during module flashing.
[2]
The Green wire is ONLY required for starter disable and antigrind applications.
[3]
The EMS COM connection is NOT required in US vehicles without transponder immobilizer.
[4]
Required ONLY if RAP Off does not operate over data.
[5]
5
933.HKHT1 3.20.193.1 2012 Hyundai Accent
© 2019-03-20 Directed. All rights reserved.
THHYN3 Keys required for 1 Keys required for
programming operation
