Vehicle connections

The connection information listed below is specific to the 2012 Hyundai Accent. Refer to "Pre-installation and application warnings" for a list of important notes.
Data harness, 8-pin white connector (H1)
Module
Conn./Pin Color Description
H1/1 Tan (Data) HS CAN Low
H1/2 Tan/Black (Data) HS CAN High
H1/3 Orange/Brown (Data) FT CAN Low
H1/4 Orange/Green (Data) FT CAN High
H1/5 Lt. Green No Connection
H1/6 Violet/Brown No Connection
H1/7 Orange/Black (Data) Immo. Data (conn. side) [4]
H1/8 Yellow/Black (Data) Immo. Data (vehicle side) [4]
Analog input/output harness, 22-pin white connector (H2)
Module
Conn./Pin Color Description
H2/1 Lt. Green/Black (-) Parking Light Output
H2/2 Blue/White (-) Ground When Running (Status) Output
H2/3 Dk. Green/Black (-) Lock Output
H2/4 Red/White (-) Trunk Release Output
H2/5 Brown/Black (-) Horn Output
H2/6 Brown/White (-) RAP Off Output [5]
H2/7 White (+) (+) AUX 2 Output
H2/8 Violet/Black (+) AUX 3 Output
H2/9 Dk. Blue/Black (-) Unlock Output
H2/10 Lt. Blue/Black (-) Factory Alarm Disarm Output
H2/11 Brown/Red (+) Siren Output [2]
H2/12 Pink (+) Ignition Sense Input
H2/13 Violet (+) Door Input
H2/14 Brown (+) Brake Input
H2/15 White/Blue (-) Activation Input
H2/16 Red/Blue (-) Valet switch
11 933.HKHT1 3.20.193.1 2012 Hyundai Accent
© 2019-03-20 Directed. All rights reserved.
Connects To
Wire Location
OBD-data link connector, black 16 pin plug, pin 14
OBD-data link connector, black 16 pin plug, pin 6
No Connection
No Connection
No Connection
No Connection
left of dash fuse box, black 21 pin plug, pin 11
left of dash fuse box, black 21 pin plug, pin 11
Connects To
Wire Location
headlight switch, white 14 pin plug, pin 7
No Connection
driver kick, white 39 pin plug, pin 15
With OEM Alarm.
Must use 2 1A diodes.
Not Applicable
No Connection
No Connection
driver kick, white 39 pin plug, pin 2
No Connection
No Connection
driver kick, white 39 pin plug, pin 16
With OEM Alarm.
Must use 2 1A diodes.
driver kick, white 39 pin plug, pin 38
With OEM Alarm.
driver kick, white 39 pin plug, pin 20
No Connection
No Connection
No Connection
No Connection
No Connection
(+/-) Wire Color Connection
data orange (C-CAN) Mandatory
data green (C-CAN) Mandatory
data blue/orange (EMS COM) Remote Start
Only
data blue/orange (EMS COM) Remote Start
Only
(+/-) Wire Color Connection
- pink/black Mandatory
- brown (with BCM) Mandatory
- brown/orange Remote Start
Only
- gray (with BCM) Mandatory
open blue/black
doubl gray/orange Mandatory
e -
Security Only
