Parameter Description
8-05 End-of-Timeout Function
Option: Function:
[1] Resume set- Resumes the set-up active prior to the time-
*
up out.
8-06 Reset Control Timeout
Option: Function:
This parameter is active only when the choice Hold
set-up [0] has been selected in 8-05 End-of-Timeout
Function .
[0] Do not Retains the set-up specified in 8-04 Control Timeout
*
reset Function, [Select setup 1-4] following a control
time-out.
[1] Do reset Returns the frequency converter to the original
set-up following a control word time-out. When
the value is set to Do reset [1], the frequency
converter performs the reset and then
immediately reverts to the Do not reset [0] setting.
8-07 Diagnosis Trigger
Option: Function:
This parameter has no function for
BACnet.
[0] Disable
*
[1] Trigger on alarms
[2] Trigger alarm/warn.
3.9.2 8-1* Ctrl. Word Settings
8-10 Control Profile
Option: Function:
Select the interpretation of the control
and status words corresponding to the
installed fieldbus. Only the selections
valid for the fieldbus installed in slot A
will be visible in the LCP display.
[0] FC profile
*
[1] PROFIdrive profile
[5] ODVA
[7] CANopen DSP 402
8-13 Configurable Status Word STW
Option: Function:
This parameter enables configuration of
bits 12 – 15 in the status word.
[0] No function The input is always low.
[1] Profile Default Depended on the profile set in 8-10 Control
*
Profile.
[2] Alarm 68 Only The input will go high whenever Alarm 68
is active and will go low whenever no
alarm 68 is active
[3] Trip excl Alarm The input will go high whenever Trip on
68 other Alarms then Alarm 68 is active.
®
VLT HVAC Drive Programming Guide
8-13 Configurable Status Word STW
Option:
[10] T18 DI status.
[11] T19 DI status.
[12] T27 DI status.
[13] T29 DI status.
[14] T32 DI status.
[15] T33 DI status.
[16] T37 DI status
[21] Thermal
[30] Brake fault
[40] Out of ref range If Comparator 0 is evaluated as TRUE, the
[60] Comparator 0
[61] Comparator 1
[62] Comparator 2
[63] Comparator 3
[64] Comparator 4
[65] Comparator 5
[70] Logic Rule 0
[71] Logic Rule 1
[72] Logic Rule 2
[73] Logic Rule 3
[74] Logic Rule 4
[75] Logic Rule 5
[80] SL Digital
[81] SL Digital
®
