Parameter Description
13-40 Logic Rule Boolean 1
Array [6]
Option:
[61] Logic rule 5
3 3
[70] SL Time-out 3
[71] SL Time-out 4
[72] SL Time-out 5
[73] SL Time-out 6
[74] SL Time-out 7
[76] Digital Input x30 2
[77] Digital Input x30 3
[78] Digital Input x30 4
[80] No Flow
[81] Dry Pump
[82] End of Curve
[83] Broken Belt
[90] ECB Drive Mode
[91] ECB Bypass Mode
[92] ECB Test Mode
[100] Fire Mode
13-41 Logic Rule Operator 1
Array [6]
Option:
[0] DISABLED
*
[1] AND
[2] OR
[3] AND NOT
[4] OR NOT
[5] NOT AND
[6] NOT OR
98
®
VLT HVAC Drive Programming Guide
Function:
Use the result of logic rule 5 in the
logic rule.
Use the result of timer 3 in the logic
rule.
Use the result of timer 4 in the logic
rule.
Use the result of timer 5 in the logic
rule.
Use the result of timer 6 in the logic
rule.
Use the result of timer 7 in the logic
rule.
Function:
Select the first logical operator to use on the
Boolean inputs from 13-40 Logic Rule Boolean
1 and 13-42 Logic Rule Boolean 2.
[13 -XX] signifies the boolean input of
parameter group 13-*.
Ignores 13-42 Logic Rule Boolean 2,
13-43 Logic Rule Operator 2, and 13-44 Logic
Rule Boolean 3.
Evaluates the expression [13-40] AND
[13-42].
evaluates the expression [13-40] OR[13-42].
evaluates the expression [13-40] AND NOT
[13-42].
evaluates the expression [13-40] OR NOT
[13-42].
evaluates the expression NOT [13-40] AND
[13-42].
evaluates the expression NOT [13-40] OR
[13-42].
MG.11.CB.02 - VLT
13-41 Logic Rule Operator 1
Array [6]
Option:
[7] NOT AND NOT evaluates the expression NOT [13-40] AND
[8] NOT OR NOT
13-42 Logic Rule Boolean 2
Array [6]
Option:
[0] False
*
[1] True
[2] Running
[3] In range
[4] On reference
[5] Torque limit
[6] Current limit
[7] Out of current range
[8] Below I low
[9] Above I high
[10] Out of speed range
[11] Below speed low
[12] Above speed high
[13] Out of feedb. range
[14] Below feedb. low
[15] Above feedb. high
[16] Thermal warning
[17] Mains out of range
[18] Reversing
[19] Warning
[20] Alarm (trip)
[21] Alarm (trip lock)
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[30] SL Time-out 0
[31] SL Time-out 1
[32] SL Time-out 2
[33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27
®
is a registered Danfoss trademark
Function:
NOT [13-42].
evaluates the expression NOT [13-40] OR
NOT [13-42].
Function:
Select the second boolean (TRUE or
FALSE) input for the selected logic
rule.
See 13-40 Logic Rule Boolean 1 for
further descriptions of choices and
their functions.
