Danfoss VLT Programming Manual page 181

Parameter Description
26-15 Term. X42/1 High Ref./Feedb. Value
Range:
100.000 [-999999.999 -
*
999999.999 ]
3 3
26-16 Term. X42/1 Filter Time Constant
Range:
0.001 s [0.001 -
*
10.000 s]
26-17 Term. X42/1 Live Zero
Option:
[0] Disabled
[1] Enabled
*
3.24.3 26-2* Analog Input X42/3
Parameters for configuring the scaling and limits for analog
input, terminal X42/3.
26-20 Terminal X42/3 Low Voltage
Range:
0.07 V [0.00 - par.
*
6-31 V]
26-21 Terminal X42/3 High Voltage
Range:
10.00 V [par. 6-30 -
*
10.00 V]
26-24 Term. X42/3 Low Ref./Feedb. Value
Range:
0.000 [-999999.999 -
*
999999.999 ]
180
VLT
Function:
Enter the analog input scaling
value that corresponds to the
high voltage value set in
26-11 Terminal X42/1 High
Voltage.
Function:
Enter the time constant. This is a first-order
digital low pass filter time constant for
suppressing noise in terminal X42/1. A high
time constant value improves dampening
but also increases the time delay through
the filter. This parameter cannot be
adjusted while the motor is running.
Function:
This parameter makes it possible to enable the Live
Zero monitoring. E.g. where the analog input is a
part of the frequency converter control, rather than
being used as part of a decentral I/O system, such
as a Building Management System.
Function:
Enter the low voltage value. This analog
input scaling value should correspond to
the low reference/feedback value set in
26-24 Term. X42/3 Low Ref./Feedb. Value.
Function:
Enter the high voltage value. This
analog input scaling value should
correspond to the high reference/
feedback value set in 26-25 Term. X42/3
High Ref./Feedb. Value.
Function:
Enter the analog input scaling
value that corresponds to the low
voltage value set in 26-20 Terminal
X42/3 Low Voltage.
MG.11.CB.02 - VLT
®
HVAC Drive Programming Guide
26-25 Term. X42/3 High Ref./Feedb. Value
Range:
100.000
*
999999.999 ]
26-26 Term. X42/3 Filter Time Constant
Range:
0.001 s [0.001 -
*
10.000 s]
26-27 Term. X42/3 Live Zero
Option:
[0] Disabled
[1] Enabled
*
3.24.4 26-3* Analog Input X42/5
Parameters for configuring the scaling and limits for analog
input, terminal X42/5.
26-30 Terminal X42/5 Low Voltage
Range:
0.07 V [0.00 - par.
*
6-31 V]
26-31 Terminal X42/5 High Voltage
Range:
10.00 V [par. 6-30 -
*
10.00 V]
26-34 Term. X42/5 Low Ref./Feedb. Value
Range:
0.000 [-999999.999 -
*
999999.999 ]
®
is a registered Danfoss trademark
Function:
[-999999.999 - Enter the analog input scaling
value that corresponds to the
high voltage value set in
26-21 Terminal X42/3 High
Voltage.
Function:
Enter the time constant. This is a first-order
digital low pass filter time constant for
suppressing noise in terminal X42/3. A high
time constant value improves dampening
but also increases the time delay through
the filter. This parameter cannot be
adjusted while the motor is running.
Function:
This parameter makes it possible to enable the Live
Zero monitoring. E.g. where the analog input is a
part of the frequency converter control, rather than
being used as part of a decentral I/O system, such
as a Building Management System.
Function:
Enter the low voltage value. This analog
input scaling value should correspond to
the low reference/feedback value set in
26-34 Term. X42/5 Low Ref./Feedb. Value.
Function:
Enter the high voltage value. This
analog input scaling value should
correspond to the high reference/
feedback value set in 26-35 Term. X42/5
High Ref./Feedb. Value.
Function:
Enter the analog input scaling
value that corresponds to the low
voltage value set in 26-30 Terminal
X42/5 Low Voltage.
