Parameter Description
0-13 Readout: Linked Set-ups
Array [5]
Range: Function:
0 [0 - View a list of all the set-ups linked by means of 0-12 This
255 ] Set-up Linked to. The parameter has one index for each
*
parameter set-up. The parameter value displayed for
each index represents which setups are linked to that
parameter setup.
Index LCP value
0 {0}
1 {1,2}
2 {1,2}
3 {3}
4 {4}
Table 3.2 Example: Set-up 1 and Set-up 2 are linked
0-14 Readout: Prog. Set-ups / Channel
Range: Function:
0 [-2147483648 - View the setting of 0-11 Programming Set-up
*
2147483647 ] for each of the four different communication
channels. When the number is displayed in
hex, as it is in the LCP, each number
represents one channel.
Numbers 1-4 represent a set-up number; 'F'
means factory setting; and 'A' means active
set-up. The channels are, from right to left:
LCP, FC-bus, USB, HPFB1.5.
Example: The number AAAAAA21h means
that the FC-bus selected Set-up 2 in
0-11 Programming Set-up, the LCP selected
Set-up 1 and all others used the active set-
up.
3.2.3 0-2* LCP Display
Define the variables displayed in the Graphical Local Control
Panel.
NOTE
Please refer to 0-37 Display Text 1, 0-38 Display Text 2 and
0-39 Display Text 3 for information on how to write display
texts.
0-20 Display Line 1.1 Small
Option: Function:
Select a variable for display in line 1,
left position.
[0] None No display value selected
*
[37] Display Text 1 Enables an individual text string to
be written, for display in the LCP or
to be read via serial communication.
®
VLT HVAC Drive Programming Guide
0-20 Display Line 1.1 Small
Option:
[38]
[39]
[89]
[953]
[1005]
[1006]
[1007]
[1013]
[1115]
[1117]
[1118]
[1501]
[1502]
[1600]
[1601]
[1602]
[1603]
[1605]
[1609]
®
MG.11.CB.02 - VLT is a registered Danfoss trademark
Function:
Display Text 2 Enables an individual text string to
be written, for display in the LCP or
to be read via serial communication.
Display Text 3 Enables an individual text string to
be written, for display in the LCP or
to be read via serial communication.
Date and Time Displays the current date and time.
Readout
Profibus Warning Displays Profibus communication
Word warnings.
Readout Transmit View the number of CAN control
Error Counter transmission errors since the last
power-up.
Readout Receive View the number of CAN control
Error Counter receipt errors since the last power-
up.
Readout Bus Off View the number of Bus Off events
Counter since the last power-up.
Warning View a DeviceNet-specific warning
Parameter word. One separate bit is assigned to
every warning.
LON Warning Shows the LON-specific warnings.
Word
XIF Revision Shows the version of the external
interface file of the Neuron C chip on
the LON option.
LonWorks Revision Shows the software version of the
application program of the Neuron C
chip on the LON option.
Running Hours View the number of running hours of
the motor.
kWh Counter View the mains power consumption
in kWh.
Control Word View the Control Word sent from the
frequency converter via the serial
communication port in hex code.
Reference [Unit] Total reference (sum of digital/
analog/preset/bus/freeze ref./catch
up and slow-down) in selected unit.
Reference [%] Total reference (sum of digital/
*
analog/preset/bus/freeze ref./catch
up and slow-down) in percent.
Status Word Present status word
Main Actual Value View the two-byte word sent with
[%] the Status word to the bus Master
reporting the Main Actual Value.
Custom Readout View the user-defined readouts as
defined in 0-30 Custom Readout Unit,
