Parameter Description
16-71 Relay Output [bin]
Range:
0 [0 - 511 ]
*
3 3
16-72 Counter A
Range:
0 [-2147483648 -
*
2147483647 ]
16-73 Counter B
Range:
0 [-2147483648 -
*
2147483647 ]
16-75 Analog In X30/11
Range:
0.000 [-20.000 - 20.000 ] View the actual value at input X30/11
*
16-76 Analog In X30/12
Range:
0.000 [-20.000 - 20.000 ] View the actual value at input X30/12
*
16-77 Analog Out X30/8 [mA]
Range:
0.000 [0.000 - 30.000 ] View the actual value at input X30/8 in
*
118
®
VLT HVAC Drive Programming Guide
Function:
View the settings of all relays.
R eadout choic e (P ar . 16-71):
R ela y output (bin):
0 0 0 0 0 bin
OptionB car d r ela y 09
OptionB car d r ela y 08
OptionB car d r ela y 07
P o w er car d r ela y 02
P o w er car d r ela y 01
Function:
View the present value of Counter A.
Counters are useful as comparator
operands, see 13-10 Comparator Operand.
The value can be reset or changed either
via digital inputs (parameter group 5-1*) or
by using an SLC action (13-52 SL Controller
Action).
Function:
View the present value of Counter B.
Counters are useful as comparator
operands (13-10 Comparator Operand).
The value can be reset or changed either
via digital inputs (parameter group 5-1*) or
by using an SLC action (13-52 SL Controller
Action).
Function:
of MCB 101.
Function:
of MCB 101.
Function:
mA.
MG.11.CB.02 - VLT
3.16.6 16-8* Fieldbus & FC Port
Parameters for reporting the BUS references and control
words.
16-80 Fieldbus CTW 1
Range: Function:
0 [0 - 65535 ] View the two-byte Control word (CTW) received
*
from the Bus-Master. Interpretation of the
Control word depends on the fieldbus option
installed and the Control word profile selected
in 8-10 Control Profile.
For more information please refer to the
relevant fieldbus manual.
16-82 Fieldbus REF 1
Range: Function:
0 [-200 - 200 ] View the two-byte word sent with the control
*
word form the Bus-Master to set the reference
value.
For more information please refer to the
relevant fieldbus manual.
16-84 Comm. Option STW
Range: Function:
0 [0 - 65535 ] View the extended fieldbus comm. option
*
status word.
For more information please refer to the
relevant fieldbus manual.
16-85 FC Port CTW 1
Range: Function:
0 [0 - 65535 ] View the two-byte Control word (CTW) received
*
from the Bus-Master. Interpretation of the
control word depends on the fieldbus option
installed and the Control word profile selected
in 8-10 Control Profile.
16-86 FC Port REF 1
Range: Function:
0 [-200 - 200 ] View the two-byte Status word (STW) sent to
*
the Bus-Master. Interpretation of the Status
word depends on the fieldbus option installed
and the Control word profile selected in
8-10 Control Profile.
3.16.7 16-9* Diagnosis Read-Outs
16-90 Alarm Word
Range:
0 [0 - 4294967295 ] View the alarm word sent via the serial
*
®
is a registered Danfoss trademark
Function:
communication port in hex code.
