Parameter Description
[66] Sleep Mode
[68] Timed Actions
Disabled
3 3 [69] Constant OFF
[70] Constant ON
[78] Reset
Preventive
Maintenance
Word
5-10 Terminal 18 Digital Input
Same options and functions as 5-1*, except for Pulse input.
Option:
[8]
*
5-11 Terminal 19 Digital Input
Same options and functions as 5-1*, except for Pulse input.
Option:
[0]
*
5-12 Terminal 27 Digital Input
Option:
[2] Coast inverse Functions are described under 5-1* Digital
*
5-13 Terminal 29 Digital Input
Option: Function:
Select the function from the available digital input
range and the additional options [60], [61], [63] and
[64]. Counters are used in Smart Logic Control
functions.This parameter is available for FC 302 only.
[14] Jog Functions are described under 5-1* Digital Inputs
*
5-14 Terminal 32 Digital Input
Option:
[0] No Operation Same options and functions as par. 5-1*
*
5-15 Terminal 33 Digital Input
Option:
[0] No Operation Same options and functions as par. group 5-1*
*
5-16 Terminal X30/2 Digital Input
This parameter is active when option module MCB 101 is installed
in the frequency converter. Same options and functions as par.
group 5-1* except for Pulse input [32].
Option:
[0]
*
60
VLT
Forces frequency converter into Sleep Mode
(see par. 22-4*). Reacts on the rising edge of
signal applied!
Timed actions are disabled. See parameter
group 23-0* Timed Actions.
Timed Actions are set for Constant OFF. See
parameter group 23-0* Timed Actions.
Timed Actions are set for Constant ON. See
parameter group 23-0* Timed Actions.
Resets all data in 16-96 Maintenance Word to
0.
Function:
Start
Function:
No operation
Function:
Inputs
Function:
Digital Inputs, except for Pulse input.
Function:
Digital Inputs.
Function:
No operation
MG.11.CB.02 - VLT
®
HVAC Drive Programming Guide
5-17 Terminal X30/3 Digital Input
This parameter is active when option module MCB 101 is installed
in the frequency converter. Same options and functions as par.
group 5-1* except for Pulse input [32].
Option:
[0]
*
5-18 Terminal X30/4 Digital Input
This parameter is active when option module MCB 101 is installed
in the frequency converter. Same options and functions as par.
group 5-1* except for Pulse input [32].
Option:
[0]
*
3.7.4 5-3* Digital Outputs
Parameters for configuring the output functions for the
output terminals. The 2 solid-state digital outputs are
common for terminals 27 and 29. Set the I/O function for
terminal 27 in 5-01 Terminal 27 Mode and set the I/O function
for terminal 29 in 5-02 Terminal 29 Mode. These parameters
cannot be adjusted while the motor is running.
[0] No operation
[1] Control ready
[2] Drive ready
[3] Drive ready /
remote
control
[4] Stand-by / no
warning
[5] Running
[6] Running / no
warning
[8] Run on
reference / no
warning
[9] Alarm
[10] Alarm or
warning
[11] At torque
limit
[12] Out of current
range
[13] Below current,
low
®
is a registered Danfoss trademark
Function:
No operation
Function:
No operation
The digital outputs can be programmed
with these functions:
Default for all digital outputs and relay
outputs
The control board receives supply voltage.
The frequency converter is ready for
operation and applies a supply signal on the
control board.
The frequency converter is ready for
operation and is in Auto On mode.
The frequency converter is ready for
operation. No start or stop command is been
given (start/disable). There are no warnings.
The motor is running.
The output speed is higher than the speed
set in 1-81 Min Speed for Function at Stop
[RPM]. The motor is running and there are no
warnings.
The motor runs at reference speed.
An alarm activates the output. There are no
warnings.
An alarm or a warning activates the output.
The torque limit set in 4-16 Torque Limit
Motor Mode or par. 4-17 has been exceeded.
The motor current is outside the range set in
4-18 Current Limit.
The motor current is lower than set in
4-50 Warning Current Low.
