26-44 Terminal X42/7 Timeout Preset
Range:
0.00 % [0.00 - 100.00
*
%]
3 3
3.24.6 26-5* Analog Out X42/9
Parameters for configuring the scaling and output function
for analog output, terminal X42/9.
26-50 Terminal X42/9 Output
Option:
[0] No operation
*
[100] Output freq.
0-100
[101] Reference Min-
Max
[102] Feedback +-200% : -200% to +200% of 20-14 Maximum
[103] Motor cur. 0-Imax : 0 - Inverter Max. Current (16-37 Inv. Max.
[104] Torque 0-Tlim
[105] Torque 0-Tnom
[106] Power 0-Pnom
[107] Speed 0-HighLim : 0 - Speed High Limit (4-13 Motor Speed
[113] Ext. Closed Loop
1
[114] Ext. Closed Loop
2
[115] Ext. Closed Loop
3
[139] Bus ctrl.
[141] Bus ctrl t.o.
26-51 Terminal X42/9 Min. Scale
Range:
0.00 % [0.00 -
*
200.00 %]
182
®
VLT HVAC Drive Programming Guide
Function:
Holds the preset level of terminal X42/7.
In case of a bus timeout and a timeout
function is selected in 26-50 Terminal
X42/9 Output the output will preset to this
level.
Function:
Set the function of terminal X42/9.
: 0 - 100 Hz, (0-20 mA)
: Minimum reference - Maximum
reference, (0-20 mA)
Reference/Feedb., (0-20 mA)
Current), (0-20 mA)
: 0 - Torque limit (4-16 Torque Limit Motor
Mode), (0-20 mA)
: 0 - Motor rated torque, (0-20 mA)
: 0 - Motor rated power, (0-20 mA)
High Limit [RPM] and 4-14 Motor Speed
High Limit [Hz]), (0-20 mA)
: 0 - 100%, (0-20 mA)
: 0 - 100%, (0-20 mA)
: 0 - 100%, (0-20 mA)
: 0 - 100%, (0-20 mA)
: 0 - 100%, (0-20 mA)
Function:
Scale the minimum output of the selected
analog signal at terminal X42/9, as a
percentage of the maximum signal level. E.g.
if a 0 V is desired at 25% of the maximum
output value. Then programme 25%. Scaling
values up to 100% can never be higher than
the corresponding setting in 26-52 Terminal
X42/9 Max. Scale.
MG.11.CB.02 - VLT
See principle graph for 6-51 Terminal 42 Output Min Scale.
26-52 Terminal X42/9 Max. Scale
Range: Function:
100.00 [0.00 - Scale the maximum output of the selected analog
% 200.00 signal at terminal X42/9. Set the value to the
*
%] maximum value of the voltage signal output.
Scale the output to give a voltage lower than 10V
at full scale; or 10V at an output below 100% of
the maximum signal value. If 10V is the desired
output current at a value between 0-100% of the
full-scale output, programme the percentage
value in the parameter, i.e. 50% = 10V. If a voltage
between 0 and 10V is desired at maximum
output, calculate the percentage as follows:
(
desired maximum voltage
i.e.
V :
5
See principle graph for 6-52 Terminal 42 Output Max Scale.
26-53 Terminal X42/9 Bus Control
Range:
0.00 % [0.00 - 100.00 %] Holds the level of terminal X42/9 if
*
26-54 Terminal X42/9 Timeout Preset
Range:
0.00 % [0.00 - 100.00
*
%]
3.24.7 26-6* Analog Out X42/11
Parameters for configuring the scaling and output function
for analog output, terminal X42/11.
26-60 Terminal X42/11 Output
Option:
[0] No operation
*
[100] Output freq.
0-100
[101] Reference Min-
Max
[102] Feedback +-200% : -200% to +200% of 20-14 Maximum
[103] Motor cur. 0-Imax : 0 - Inverter Max. Current (16-37 Inv. Max.
[104] Torque 0-Tlim
®
is a registered Danfoss trademark
)
V
10
x 100 %
V
10
x 100 % = 200 %
V
5
Function:
controlled by bus.
Function:
Holds the preset level of terminal X42/9.
In case of a bus timeout and a timeout
function is selected in 26-60 Terminal
X42/11 Output the output will preset to
this level.
Function:
Set the function of terminal X42/11.
: 0 - 100 Hz, (0-20 mA)
: Minimum reference - Maximum
reference, (0-20 mA)
Reference/Feedb., (0-20 mA)
Current), (0-20 mA)
: 0 - Torque limit (4-16 Torque Limit Motor
Mode), (0-20 mA)
