How to Programme
It is possible to toggle between three status read-out
displays by pressing the [Status] key.
Operating variables with different formatting are shown in
2
2
each status screen - see below.
Several values or measurements can be linked to each of the
displayed operating variables. The values / measurements to
be displayed can be defined via 0-20 Display Line 1.1 Small,
0-21 Display Line 1.2 Small, 0-22 Display Line 1.3 Small,
0-23 Display Line 2 Large and 0-24 Display Line 3 Large, which
can be accessed via [QUICK MENU], "Q3 Function Setups",
"Q3-1 General Settings", "Q3-13 Display Settings".
Each value / measurement readout parameter selected in
0-20 Display Line 1.1 Small to 0-24 Display Line 3 Large has its
own scale and number of digits after a possible decimal
point. Larger numeric values are displayed with few digits
after the decimal point.
Ex.: Current readout
5.25 A; 15.2 A 105 A.
Status display I:
This read-out state is standard after start-up or initialisation.
Use [INFO] to obtain information about the value/
measurement linked to the displayed operating variables
(1.1, 1.2, 1.3, 2, and 3).
See the operating variables shown in the display in this
illustration. 1.1, 1.2 and 1.3 are shown in small size. 2 and 3
are shown in medium size.
1.1
1.2
Status display II:
See the operating variables (1.1, 1.2, 1.3, and 2) shown in the
display in this illustration.
In the example, Speed, Motor current, Motor power and
Frequency are selected as variables in the first and second
lines.
1.1, 1.2 and 1.3 are shown in small size. 2 is shown in large
size.
12
Status
799 RPM
7.83 A
0.000
53.2 %
Auto Remote Ramping
2
3
1.3
MG.11.CB.02 - VLT
®
VLT
HVAC Drive Programming Guide
Status display III:
This state displays the event and action of the Smart Logic
Control. For further information, see section Smart Logic
Control.
Display Contrast Adjustment
Press [status] and [
Press [status] and [
1 (1)
Top section
36.4 kw
Middle section
Bottom section
®
is a registered Danfoss trademark
Status
207RPM
5.25A
1.1
6.9
Hz
Auto Remote Running
Status
778 RPM
0.86 A
State: 0 o 0 (o )
When: -
Do: -
Auto Remote Running
▲
] for darker display
▼
] for brighter display
Status
43 RPM
5.44 A
1.4 Hz
2.9%
! Pwr.card temp (W29)
Auto Remote Running
1 (1)
24.4 kW
1.3
1.2
2
1 (1)
4.0 kW
!
1(1)
25.3kW
