Parameter Description
3-45 Ramp 1 S-ramp Ratio at Accel. Start
Range: Function:
50 % [Application Enter the proportion of the total ramp-
*
dependant] up time (3-41 Ramp 1 Ramp up Time) in
which the acceleration torque
increases. The larger the percentage
value, the greater the jerk compen-
sation achieved, and thus the lower the
torque jerks occurring in the
application.
3-46 Ramp 1 S-ramp Ratio at Accel. End
Range: Function:
50 % [Application Enter the proportion of the total ramp-
*
dependant] up time (3-41 Ramp 1 Ramp up Time) in
which the acceleration torque
decreases. The larger the percentage
value, the greater the jerk compen-
sation achieved, and thus the lower the
torque jerks in the application.
3-47 Ramp 1 S-ramp Ratio at Decel. Start
Range: Function:
50 % [Application Enter the proportion of the total ramp-
*
dependant] down time (3-42 Ramp 1 Ramp Down
Time) where the deceleration torque
increases. The larger the percentage
value, the greater the jerk compen-
sation achieved, and thus the lower the
torque jerks in the application.
3-48 Ramp 1 S-ramp Ratio at Decel. End
Range: Function:
50 % [Application Enter the proportion of the total ramp-
*
dependant] down time (3-42 Ramp 1 Ramp Down
Time) where the deceleration torque
decreases. The larger the percentage
value, the greater the jerk compen-
sation achieved, and thus the lower the
torque jerks in the application.
3.5.4 3-5* Ramp 2
Choosing ramp parameters, see parameter group 3-4*.
3-51 Ramp 2 Ramp Up Time
Range:
Size related [1.00 - 3600.00 s]
*
3-52 Ramp 2 Ramp Down Time
Range:
Size related [1.00 - 3600.00 s]
*
®
VLT HVAC Drive Programming Guide
3-55 Ramp 2 S-ramp Ratio at Accel. Start
Range:
50 %
3-56 Ramp 2 S-ramp Ratio at Accel. End
Range:
50 %
3-57 Ramp 2 S-ramp Ratio at Decel. Start
Range:
50 %
3-58 Ramp 2 S-ramp Ratio at Decel. End
Range:
50 %
Function:
Function:
®
MG.11.CB.02 - VLT is a registered Danfoss trademark
Function:
[Application Enter the proportion of the total ramp-
*
dependant] up time (3-51 Ramp 2 Ramp up Time) in
which the acceleration torque
increases. The larger the percentage
value, the greater the jerk compen-
sation achieved, and thus the lower the
torque jerks in the application.
Function:
[Application Enter the proportion of the total ramp-
*
dependant] up time (3-51 Ramp 2 Ramp up Time) in
which the acceleration torque
decreases. The larger the percentage
value, the greater the jerk compen-
sation achieved, and thus the lower the
torque jerks in the application.
Function:
[Application Enter the proportion of the total ramp-
*
dependant] down time (3-52 Ramp 2 Ramp down
Time) where the deceleration torque
increases The larger the percentage
value, the greater the jerk compen-
sation achieved, and thus the lower the
torque jerks in the application.
Function:
[Application Enter the proportion of the total ramp-
*
dependant] down time (3-52 Ramp 2 Ramp down
Time) where the deceleration torque
decreases. The larger the percentage
value, the greater the jerk compen-
sation achieved, and thus the lower the
torque jerks in the application.
