Parameter Description
18-32 Analog Input X42/5
Range: Function:
0.000 [-20.000 - Read out of the value of the signal applied
*
20.000 ] to terminal X42/5 on the Analog I/O Card.
The units of the value shown in the LCP will
correspond to the mode selected in
26-02 Terminal X42/5 Mode.
18-33 Analog Out X42/7 [V]
Range: Function:
0.000 [0.000 - Read out of the value of the signal
*
30.000 ] applied to terminal X42/7 on the Analog
I/O Card.
The value shown reflects the selection in
26-40 Terminal X42/7 Output.
18-34 Analog Out X42/9 [V]
Range: Function:
0.000 [0.000 - Read out of the value of the signal
*
30.000 ] applied to terminal X42/9 on the Analog
I/O Card.
The value shown reflects the selection in
26-50 Terminal X42/9 Output.
18-35 Analog Out X42/11 [V]
Range: Function:
0.000 [0.000 - Read out of the value of the signal
*
30.000 ] applied to terminal X42/11 on the Analog
I/O Card.
The value shown reflects the selection in
26-60 Terminal X42/11 Output.
3.17.4 18-5* Ref. & Feedb.
NOTE
Sensorless Readout requires set up by MCT 10 with
sensorless specific plug in.
18-50 Sensorless Readout [unit]
Range:
0.000 SensorlessUnit [-999999.999 - 999999.999
*
SensorlessUnit]
®
VLT HVAC Drive Programming Guide
Function:
®
