8.3.5 Changing the rod assy.
If the rod broke, please replace it. Before processing with assembly assure you have the
following tool and part.
No
Step 1 Use the wrench to loosen two screws
on the handle as arrow indicated.
Step 3 The length of the rope should be 33.47-35.44(in).
Name
1 L type wrench
2 Rod
Step 2 Loosen the nut of the yellow rope and
install the new rod.
