Universal Space Pin Setter Operation Manual page 25

Pin Setter Manual
8.3.4 Making the Bowling pin bottom assy.
If you already get this part and the problem happens again, please replace the string.
Step 1 Disassemble the Bowling pin
bottom assy.
Step 2 Follow instruction and tie the knots. (Figure-eight knot)
How to tie the knots? (Figure-eight knot)
Cross the string
24
04/18/2018
No Name
1 Rope
Make the string
into "8" shape
Step 2 Use the new string to bunch the
parts together as picture.
Pull the end of the
string into the first
circle.
String lock
Fastener
Pin bottom
fixed plate
Tightening the knot.
