  • Page 1 (Ticket Version) Operation Manual www.universal-space.com...

  • Page 2: Table Of Contents

    Panning for Gold (GMP Ticket ver.) Manual CONTENT IMPORTANT SAFETY INSTRUCTIONS ..............2 1. SPECIFICATIONS....................4 2. PACKAGE CONTENTS ..................5 3. PART NAME ...................... 6 4. SET UP & INSTALLATION ................7 5. HOW TO PLAY ....................10 6. GAME OPTIONS ..................... 11 7.

  • Page 3: Important Safety Instructions

    Panning for Gold (GMP Ticket ver.) Manual Thank you for purchasing Panning for Gold from Universal Space. We hope you enjoy the product. This manual contains valuable information about how to operate and maintain your game machine properly and safely. It is intended for the owner and/or personnel in charge of product operation.
  • Page 4 Panning for Gold (GMP Ticket ver.) Manual Use the following safety guidelines to help ensure your own personal safety and to help protect your equipment and surrounding environment from potential damage. This product is an indoor game machine. Do not install outdoors.

  • Page 5: Specifications

    Panning for Gold (GMP Ticket ver.) Manual 1. SPECIFICATIONS Rated power supply: AC110V 50Hz/60Hz；220V 50Hz/60 Hz Min. Power consumption: 170W Max. Power consumption：200W Dimensions： W1100×D1420×H2010 (mm) Weight： Approximately 200kg NOTICE: After turning off the game, please wait at least 1 minute before restarting again.

  • Page 6: Package Contents

    Panning for Gold (GMP Ticket ver.) Manual 2. PACKAGE CONTENTS Open the package and make sure all the items are included:  1 x Body Assembly  Following accessories Part No. Code Name Spec. Note Φ5×20mm T5A P121-440-000 21901000012 Fuse...

  • Page 7: Part Name

    Panning for Gold (GMP Ticket ver.) Manual 3. PART NAME Marquee Bonus display Speaker Weighing platform Joy stick Confirm Button Service door Coin entrance Ticket dispenser...

  • Page 8: Set Up & Installation

    Panning for Gold (GMP Ticket ver.) Manual 4. SET UP & INSTALLATION This product is an indoor game machine. Do not install outdoors.  Refer to IMPORTANT SAFETY INSTRUCTIONS (Pg. 2) for places to avoid  Place the unit on a dry level surface ...
  • Page 9 Panning for Gold (GMP Ticket ver.) Manual 4.3 Transporting the Machine If you need to move the game, adjust the levelers back to an “up” position so the casters touch the ground. Caster Leveler NOTICE  Be careful not to damage the machine during transport.
  • Page 10 Panning for Gold (GMP Ticket ver.) Manual   WARNING Ensure no heavy objects rest on the power cord. Check to make sure the game cabinet does not sit on the power cord as this could damage the cord and become hazardous.

  • Page 11: How To Play

    Panning for Gold (GMP Ticket ver.) Manual 5. HOW TO PLAY 1. Insert coin. Control the joystick to move the arm. 2. Aim for the nugget and press the button to collect as many as you can. 3. Weight the gold and pay out tickets...

  • Page 12: Game Options

    Panning for Gold (GMP Ticket ver.) Manual 6. GAME OPTIONS Check the attached I/O chart and schematic diagram, PC plan available machine input and output correspond to each connection position. Based on the DIP adjustment can be set the machine control signal.
  • Page 13 Panning for Gold (GMP Ticket ver.) Manual IO Settings Item Content Item Content 120s 180s Demo music 240s Coin Item Content game Mercy ticket Free play Item * Note: Content AUTO: Claw will close automatically when it goes down into the tub.
  • Page 14 Panning for Gold (GMP Ticket ver.) Manual ** *Note: Level1 Level2 Level 3 BONUS GRADE (ounce/gram) (ounce/gram) (ounce/gram) (ounce/gram) 0~10 11~19 20~27 ≥28 0~15 15~25 26~35 ≥36 0~20 21~30 31~40 ≥41 0~25 26~35 36~45 ≥46 ****Note: Item Content Level 1...

  • Page 15: Error Message And Recovery

    Panning for Gold (GMP Ticket ver.) Manual 7. ERROR MESSAGE AND RECOVERY 7.1 Trouble Shootings *Please confirm whether every connector connected tightly. Problem Cause Countermeasures Please check power supply suitable for Power is not supplied. Machine the machine or not.

  • Page 16: Maintenance, Inspection

    Panning for Gold (GMP Ticket ver.) Manual 8. MAINTENANCE, INSPECTION 8.1 Safety Check Check the points listed before operating the machine. These checks are necessary for safe machine operation: 1. Try to run the game before operation each day. 2. Conduct monthly routine checks of game components ensure good working condition 3.
  • Page 17 Panning for Gold (GMP Ticket ver.) Manual WARNING  • Before servicing the machine, be sure to turn power off. Servicing without turning the power off can cause electric shock or short circuit. • To avoid electric shock or short circuit, do not plug then unplug the power quickly •...

  • Page 18: Overall Construction

    Panning for Gold (GMP Ticket ver.) Manual 9. OVERALL CONSTRUCTION 9.1 .1 General Mechanism Part No. Code Name Material P121-014-000 29911413A011 Scale assy. Assy. P121-134-000 20101100024 Cross recessed pan head screw Stainless steel P121-036-000 29911413015 Pump assy. Assy. P121-039-000 29911413040 Storage tank assy.
  • Page 19 Panning for Gold (GMP Ticket ver.) Manual Part No. Code Name Material 16 P121-204-000 20611413001 Mechanism R cover 17 P121-033-000 29911413013 Power supply SW assy. Assy. Cross recessed pan head screw 18 P121-105-000 20101000034 suite 19 P121-424-000 25101210020 Air spring...
  • Page 20 Panning for Gold (GMP Ticket ver.) Manual 9.1 .3 Cabinet part Part No. Code Name Material P121-207-000 20211413005 Cabinet body Q235 P121-236-000 20211413A004 Breakwater support bracket Q235 P121-230-000 20211413026 Door lock card plate Color zinc Cross recessed pan head P121-105-000 20101000034...
  • Page 21 Panning for Gold (GMP Ticket ver.) Manual Part No. Code Name Material 11 P121-329-000 26000008000 Caster Q235 12 P121-154-000 20102000014 Hexagon nut 13 P121-210-000 20211413008 Service door Q235 14 P121-432-000 25300171001 Lock 15 P121-228-000 20611413007 Side plastic Plexi. 16 P121-159-000 20102030036...
  • Page 22 Panning for Gold (GMP Ticket ver.) Manual 9.1 .5 Basin Assy. Part No. Code Name Material P121-202-000 20611106029 Filter 2 P121-216-000 20211413013 Water outlet Brass P121-410-000 20116000192 O type rubber seal ring P121-214-000 20611413005 Basin Azure ABS P121-428-000 25106020196 PU hose...
  • Page 23 Panning for Gold (GMP Ticket ver.) Manual 9.1 .7 Counter light box Assy. 10,11 Part No. Code Name Material P121-223-000 20211413017 Score panel bracket Q235 P121-225-000 20611413006 Side lit up plastic Plexi. Cross recessed pan head screw P121-139-000 20101100037 Stainless steel...
  • Page 24 Panning for Gold (GMP Ticket ver.) Manual 9.1 .9 Middle control panel Assy. Part No. Code Name Material P121-432-000 25300171001 Lock P121-242-000 20211413041 Middle control panel door Q235 P121-241-000 20211413040 Middle control panel door hinge Q235 P121-102-000 20101000016 Cross recessed sunk head screw...
  • Page 25 Panning for Gold (GMP Ticket ver.) Manual Part No. Code Name Material Qty P121-250-000 20611413024 Control panel plexi. Plexi. P121-408-000 20108010009 Hexagon bolt Brass P121-246-000 20211413A007 L control panel plate Q235 10 P121-012-000 29911413023 Front & back shift SW Assy.
  • Page 26 Panning for Gold (GMP Ticket ver.) Manual 9.1 .12 Scale base Assy. Part No. Code Name Material P121-253-000 20211413054 Scale base Q235 P121-015-000 29911413024 Scale mechanism Assy. P121-161-000 20102100011 Hexagon flange nut Stainless steel P121-016-000 29911413025 Scale motor assy. Assy.
  • Page 27 Panning for Gold (GMP Ticket ver.) Manual 9.1 .13 Scale mechanism Part No. Code Name Material P121-254-000 20211413055 Sensor holder Stainless steel 201 1 P121-255-000 20611413011 BD. slide slot Black POM Cross recessed pan head screw P121-114-000 20101000147 suite P121-256-000 20211413056...
  • Page 28 Panning for Gold (GMP Ticket ver.) Manual 9.1 .14 Scale Assy. Part No. Code Name Material Hexagon round head P121-111-000 20101000087 screw P121-261-000 20211413061 Scale eccentric weights Q235 P121-406-000 20106000290 Deep grooved ball BD. Cross recessed pan P121-125-000 20101030023 Q235...
  • Page 29 Panning for Gold (GMP Ticket ver.) Manual 9.1 .15 Light box base Assy. Part No. Code Name Material P121-266-000 20211413066 Marquee holder Q245 Cross recessed pan head P121-120-000 20101020024 Q235 screw P121-018-000 29911413026 Speaker Assy. P121-470-000 22801000003 Hi-mid Speaker Cross recessed pan head...
  • Page 30 Panning for Gold (GMP Ticket ver.) Manual 9.1 .16 Light box Assy. Part No. Code Name Material P121-271-000 20211413069 Marquee fixed bracket Q235 P121-130-000 20101100010 Cross recessed sunk head screw Stainless steel P121-506-000 20311413006 Marquee bed plate MDF JQ11067 P121-268-000 20211413067...
  • Page 31 Panning for Gold (GMP Ticket ver.) Manual 9.1 .18 Window Assy. Part No. Code Name Material P121-309-000 20211413107 Window frame Q235 P121-310-000 20211413108 Window hinge Q235 Cross recessed sunk head P121-152-000 20101102008 Stainless steel screw Transparent P121-311-000 20611413022 Window transparent plate...
  • Page 32 Panning for Gold (GMP Ticket ver.) Manual 9.1 .19 Arm Mechanism Part No. Code Name Material P121-026-000 29911413030 Rotating motor assy. Assy. Cross recessed pan head P121-137-000 20101100035 Stainless steel screw suite P121-273-000 20211413079 Catcher bracket Q235 P121-284-000 20211413090 Limited block...
  • Page 33 Panning for Gold (GMP Ticket ver.) Manual 9.1 .20 Rotating motor Assy. Part No. Code Name Material Qty P121-281-000 20211413087 Rotating motor mounted plate Q235 P121-600-000 23404000085 DC motor P121-104-000 20101000021 Cross recessed pan head screw 9.1 .21 Rotating Assy.
  • Page 34 Panning for Gold (GMP Ticket ver.) Manual 9.1 .22 Sensor bracket Assy. Part No. Code Name Material P121-283-000 20211413089 Sensor mounted plate A Stainless steel 201 Cross recessed pan P121-117-000 20101000186 Q235 head screw suite P121-282-000 20211413088 Located sensor holder Stainless steel 201 9.1 .23 Swing motor Assy.
  • Page 35 Panning for Gold (GMP Ticket ver.) Manual 9.1 .24 Connection rod Assy. Part No. Code Name Material P121-288-000 20211413128 Connection rod lengthen bar Weld assy. P121-407-000 20106080312 Rod end knuckle BD. P121-155-000 20102000030 Hexagon flange nut 9.1 .25 Catcher Assy.
  • Page 36 Panning for Gold (GMP Ticket ver.) Manual Part No. Code Name Material P121-412-000 23404000098 DC motor P121-104-000 20101000021 Cross recessed pan head screw P121-299-000 20211413100 Cable sleeve Aluminum alloy P121-297-000 20611413017 Reel White POM P121-296-000 20211413098 Short shaft A Q235...
  • Page 37 Panning for Gold (GMP Ticket ver.) Manual 9.1 .28 Water pump Assy Part No. Code Name Material P121-318-000 20211413113 Water pump holder Stainless steel304 P121-153-000 20101180101 Hexagon head seal screw suite Stainless steel P121-414-000 23410000207 Brushless DC water pump P121-319-000 20211413114...
  • Page 38 Panning for Gold (GMP Ticket ver.) Manual 9.2.1 Electrical Part...

  • Page 39: P121-484-000

    Panning for Gold (GMP Ticket ver.) Manual Part No. Code Name Material DC12V 3528LED 60z/m P121-487-000 22002013004 LED light belt blue 4500mm TKTTQ-LED23B3.PCB(V1. P121-452-000 29741213010 PCB board Speaker light P121-471-000 29751301003 LED-SP.PCB(V1.0) P121-470-000 22801000003 Speaker DC12V 3528LED 60z/m P121-488-000 22002013003...
  • Page 40 Panning for Gold (GMP Ticket ver.) Manual...
  • Page 41 Panning for Gold (GMP Ticket ver.) Manual Part No. Code Name Material P121-482-000 22601010003 Door SW SB175 P121-480-000 22140000016 Relay OMRON LLY2/DC12V P121-481-000 22140000012 Relay holder OMRON PTF08A P121-443-000 21602000094 Power supply MW-S-150-12(12V/12.5A) 1 MW-ADS-15512(12V/11A, P121-444-000 21602000093 Power supply 5V/3A)
  • Page 42 Panning for Gold (GMP Ticket ver.) Manual Part No. Code Name Material P121-449-000 29740917006 PCB board XMJZ-LEDKZ.PCB(V1.1) P121-446-000 29711006006 PCB board XHZJ-BFBZ.PCB(V1.0) P121-450-000 20711413005 Motor brake pcb (JSH0265A) P121-456-000 29711413001 PCB board TJL-HX711.PCB(V1.0) P121-447-000 29711208001 PCB board MOS-DRV(V1.0) P121-448-000 29741315004 Motor drive pcb L6203-4DRV.PCB(V1.2)

  • Page 43: Decal

    Panning for Gold (GMP Ticket ver.) Manual 10. Decal Part No. Code Name Material P121-702-000 20511413001 Marquee decal δ4 plexi. P121-704-000 20511413002 Top decal δ3 plexi. P121-703-000 20511413G001 Speaker decal δ10 plexi. P121-707-000 20511413G003 Score decal 02 δ5 plexi. P121-705-000 20511413G002 Score decal 01 δ5 plexi.
  • Page 44 Panning for Gold (GMP Ticket ver.) Manual Part No. Code Name Material P121-722-000 20511413020 Motor cover plate decal P121-732-000 20511413037 Gold mine car vacuum foam Plexi. P121-733-000 20511413038 Gold mine car decal P121-743-000 25600000067 Service label PVC100u P121-742-000 25600000042 Service label 1...
  • Page 45 Panning for Gold (GMP Ticket ver.) Manual Part No. Code Name Material Qty P121-747-000 20511413039 Storage tank label PVC100u English CE certification 220V P121-748-000 20511413040 1MMPVC nameplate...

  • Page 46: Wiring Diagram

    Panning for Gold (GMP Ticket ver.) Manual WIRING DIAGRAM TJL-PX-20 TJL-PX-02...
  • Page 47 Panning for Gold (GMP Ticket ver.) Manual...
  • Page 48 Panning for Gold (GMP Ticket ver.) Manual...
  • Page 49 Panning for Gold (GMP Ticket ver.) Manual...
