Pin Setter Manual
8.3.1 Changing the pushing rod nylon wiring.
Before processing with assembly assure you have the following tool and part.
Step 1
Tie a knot on one side of the Nylon wiring and guide it through two holes of the
pushing rods as red arrow indicated.
Step 2
Wrap around and tighten the nylon wiring as red area indicated. Cut the unnecessary part.
20
04/18/2018
No
Name
Phillips screwdriver
1
Nylon wiring
2
Pushing
rod
Pushing
rod
