8. MAINTENANCE & INSPECTION
8.1 Safety Check
Check the points listed before operating the machine. These checks are necessary for safe
machine operation:
1. Test game before operation each day.
2. Conduct monthly routine checks of game components to ensure good working
condition
3. Check the machine regularly for dust and clean when necessary.
Note: Parts and components require preventative maintenance to maintain proper
operation.
8.2 Handling Precautions
When installing or inspecting the machine, be very careful of the following points and
pay attention to ensure that the player can enjoy the game safely.
Non-compliance with the following points or inappropriate handling running counter to the
cautionary matters herein stated can cause personal injury or damage to the machine
We do not recommend using power tools as they may cause damage.
8.3 Parts replacement
Before processing with assembly assure you have the following tools.
No.
Name
Phillips screwdriver
1
Wrench
2
L type wrench
3
Circlip pliers
4
NOTICE

Pin Setter Manual
Use for
8.3.1 Changing the pushing
rod nylon wiring.
& 8.3.3 Changing the Bowling
pin bottom assy.
8.3.2 Changing the turntable
assy.
8.3.3 Changing the Bowling
pin bottom assy.
& 8.3.5 Changing the rod assy.
8.3.3 Changing the Bowling
pin bottom assy.
