5.2

Software update

5.2.1

Prerequisites

You need the following items to make a software update:
• One computer with a standard LAN port available.
• A standard Internet browser.
• 1024×768 pixels or higher display resolution (best viewed with small fonts).
• One straight LAN cable.
• Access to the file with the new software.
5.2.2

Software update procedure

EXPLORER 3075GX (GX modem has separate software)
1. Power up the EXPLORER 3075GX system.
2. Connect a PC to LAN interface 1 (Service port, standard).
3. Open your Internet browser and enter the IP address of the EXPLORER 3075GX. The
default IP address is http://192.168.0.1.
4. Type in the user name admin and the admin password
or
press and hold the left arrow key for 5 seconds and enter the user name admin.
5. The web interface shows the DASHBOARD page.
6. Click SERVICE in the navigation pane. The UPLOAD SOFTWARE TO TERMINAL
page is displayed.
7. Click Browse... and locate the new software file.
98-144390-C
Figure 5-9: Software update with the web interface
Chapter 5: Service
Software update
5-9
