Self Test - COBHAM EXPLORER 3075GX User & Installation Manual

• Satellites - Satellites profiles
• Operation - Current modem and navigation parameters.
• POST - results of the Power-On-Self-Test
• Active Events - lists the currently active events
• Events - List of all cleared events.
• System log
Event list
When an event (system message) is registered, the web interface shows an event icon
in the icon bar as long as the event is active. The ACU display shows also active
events. To view the event list with active events, click the event icon from the icon bar at
the top of the web interface, or select HELPDESK > Event list from the left navigation
pane.
The Event list page shows a detailed list of active events and notifications including the
time of the first occurrence, ID and severity of the event message, and a short text
describing the error. Active events are cleared from the event list when the error is cleared.
They are moved to the section Notifications and are displayed for 24 hours. All entries in
the section Notifications are cleared automatically after 24 hours and after restart of the
system. For a list of all events with description, error code (ID), explanation and remedy see
System messages on page B-1.

Self test

You can start a self test of the EXPLORER 3075GX. The self test checks all vital parts of the
unit. If a malfunction is detected, the unit provides system messages with a description of
the failing test. This is indicated by
messages are listed in System messages on page B-1.
To make a self test, do as follows:
1. Click Self test in the HELPDESK page.
2. Click the menu item
Important
98-144390-C
in the icon bar and in the ACU display. All system
Self test
.
Warning! The EXPLORER 3075GX will reboot to perform the self test. A
reboot terminates all existing connections.
Chapter 5: Service
General support
5-3
