User Permissions (Guest Login) - COBHAM EXPLORER 3075GX User & Installation Manual

Setup with the web interface for PC
To change the administrator password, do as follows:
1. In the section Change Logon enter the current password.
2. Type the new password and retype it on the next line.
3. Click Change. At the next logon the new password is required.
To reset the administrator password, do as follows:
1. On the ACU keypad, push and hold the left arrow key for 5 seconds.
2. Wait for the very short display of Local administration, followed by the event text:
0807F-0 WARNING Local administration enabled.
This will give you temporary administrator access for 1 hour or until next restart.
3. Open your browser and access the web interface.
4. Enter user name: admin (no password is required).
The DASHBOARD is displayed.
Note
5. To enter or change the password select ADMINISTRATION > User login and locate
the section Change Login.
6. If needed, type in the new password (minimum 8 characters) and click Change. No old
password is required.
After the 1 hour window or a restart the administrator password is required.
To log off administration
If you have not entered anything for 30 minutes under ADMINISTRATION, you are
logged off automatically. To log off manually, click Logoff.
4.1.7

User permissions (guest login)

You can manage user access to certain functions of the EXPLORER 3075GX system. You can
allow or deny users that are not administrators (user name: guest, password: guest) access
to certain functions and make these pages read-only. This is useful if you want to protect
the system against unintended changes or tampering of the system.
Important
To set up the user permissions for guest users, do as follows:
1. Select ADMINISTRATION > User permissions.
4-12
Accessing the ACU with the local administration function does not change the
current administrator password.
Study this screen thoroughly and decide which areas of the EXPLORER
3075GX system you want to give non-administrator users (user name:
guest) access to.
Chapter 4: Setup and operation 98-144390-C
