4.1.3
To configure the LAN network
On this page you can set up the LAN network and enter a host name. The host name helps
identifying the EXPLORER 3075GX system, e.g. in a diagnostics report. There are four
10/100 Mbit ports, labelled LAN 1, 2, 3 and 4. LAN1 is the service port. LAN2, LAN3 and
LAN4 are ports for user data and controlled by the GX modem.
Important
To configure the LAN network, do as follows:
1. Select SETTINGS > Network.
2. Make the necessary changes on this page and click Apply.
Important
98-144390-C
The EXPLORER 3075GX system is not designed to be connected directly to
the Internet. It must be located behind a dedicated network security device
such as a firewall. If any ports of the EXPLORER 3075GX are exposed to the
Internet you must change the default passwords as anyone with access and
malicious intent can render the EXPLORER 3075GX inoperable.
Figure 4-5: Web interface: SETTINGS, Network
Make sure that the networks do not use IP address ranges that overlap.
Chapter 4: Setup and operation
Setup with the web interface for PC
4-7
