• To get an overview over the submenus available, click SITE MAP in the
navigation pane. Click on items in the site map to go directly to the relevant location.
You can give access to some configuration settings for users that are not
Note
administrators. For information see User permissions (guest login) on page 4-
12.
Status field in the icon bar
The top bar shows the current signal strength and the current status of the antenna.
Examples:
• Antenna software upload
• Antenna POST (Power-On Self Test)
• Ready (waiting for data from the modem or no satellite profile selected)
Deployed idle (antenna ready)
• Manual pointing
• Acquisition OK (signal from the GX satellite acquired)
• Safe mode (error, followed by an error description)
Sections on the Dashboard
DASHBOARD
GNSS position
Satellite profile
Satellite position
RX RF frequency
Tuner signal strength
Tuner mode
Tracking RF frequency
ACU part name, Antenna
part name, ACU serial
number, Antenna serial
number, Software
version
98-144390-C
Current position, reported by the GNSS module
Name of the currently active satellite profile.
Position of the satellite selected in Satellite profile.
Ka band receiving frequency, auto-selected by modem
Current tuner signal strength
GSC (GX) or Narrow band
Current RF tracking frequency
Part names, serial numbers for antenna, software version of the
EXPLORER 3075GX.
Table 4-2: Web interface: DASHBOARD
