COBHAM EXPLORER 3075GX User & Installation Manual page 60

Specifications
Terminal
Transport cases (2)
Case with base unit and RF assembly
Dimensions (L/W/D)
Weight
Case with reflector panels, tripod and cables
Dimensions (L/W/D)
Weight
Wind Speed - Operational
Survival
Temperature - Operational, antenna
Temperature - Storage. antenna
Rain
Humidity
IP class
Coax RF Loss
DC resistance
Important
A-2
Weights and measures
Environmental characteristics
Cable requirements for TX and RX cables
After changing the TX cable you must make a One Touch Commissioning. See
GX Modem: One Touch Commissioning (OTC) on page 5-6.
Appendix A: Technical specifications
21.5 kg (47.5 lbs)
Airline checkable
62.5/50/29.7 cm (24.6/19.7/11.7 in)
<23 kg (50.7 lbs)
79.5/51.8/31 cm (31.3/20.4/12.2 in)
<23 kg (50.7 lbs)
48 km/h (30 mph) gusts up to 72 km/h (45
mph) (anchored)
129 km/h (80 mph)
-25° to +55°C (-13° to +131°F)
-40° to +80°C (-40° to +176°F)
<100 mm/hr
0 to 100% (condensing)
IP65
<3 dB @ 50 MHz
<10 dB @ 2 GHz
<1 Ohm
98-144390-C
