Introduction

1 Introduction

1.1 Purpose of the Manual

The PROFIBUS DP Programming Guide provides information
about:
•
Configuring the system.
•
Controlling the frequency converter.
•
Parameter access.
•
Programming.
•
Troubleshooting.
•
Typical application examples.
The programming guide is intended for use by qualified
personnel familiar with the VLT
PROFIBUS technology, and with the PC or PLC used as a
master in the system.
Read the instructions before programming and follow the
procedures in this manual.
®
VLT is a registered trademark.

1.2 Additional Resources

Resources available for the frequency converter and
optional equipment are:
•
The VLT® Midi Drive FC 280 Operating Guide
provides the necessary information to get the
frequency converter up and running.
•
The VLT® Midi Drive FC 280 Design Guide provides
detailed information about capabilities and
functionality to design motor control systems.
•
The VLT® Midi Drive FC 280 Programming Guide
provides more details on working with
parameters and many application examples.
Supplementary publications and manuals are available
from Danfoss. See drives.danfoss.com/knowledge-center/
technical-documentation/ for listings.

1.3 Document and Software Version

This manual is regularly reviewed and updated. All
suggestions for improvement are welcome. Table 1.1 shows
the document version and the corresponding software
version.
Edition Remarks
The first edition of this
MG07F1xx
manual.
Table 1.1 Document and Software Version
MG07F102
Programming Guide
®
frequency converter, with
Software version
Version 5.12 and above.
Danfoss A/S © 05/2016 All rights reserved.

1.4 Product Overview

1.4.1 Features of PROFIBUS DP-V1
•
Select 2 different state machines: PROFIdrive
profile or Danfoss FC profile.
•
Communication using PROFIBUS DP-V1, master
class 1, and master class 2.
•
Extension of the DP-V0 features, and backward
compatible in the sense that DP-V0 and DP-V1
products can exist in the same network.
•
Intelligent base for future technologies such as
OPC, FDT/DTM, PROFINET.
•
Bus timeout reaction.
•
PLC/CPU stop reaction.
•
8 PPO types available.
•
Numerous relevant process data (PCD) types
available.
•
Automatic detection of baud rate and PPO type.
•
Extended diagnosis available.
•
Alarms and warnings available as text messages
within the PLC.
•
Configuration via MCT 10 Set-up Software.
•
Improved network efficiency, since the cyclic
parameter channel is no longer required.
•
Short bus cycle times compared to industrial
Ethernet.
•
Backwards compatibility with DP.
1.4.2 Technical Overview
PROFIBUS
PROFIBUS is an international standard for fieldbus
communication in automation technology (IEC 61158 and
IEC 61784). The member companies of the PROFIBUS
International User Community support the standard.
For information about PROFIBUS and downloads for
PROFIBUS DP and the PROFIdrive profile, refer to
www.Profibus.com.
PROFIBUS DP-V1
The PROFIBUS DP protocol enables communication
between PROFIBUS masters and slaves.
Configure communication via MCT 10 Set-up Software.
