Parameter Access
•
RC: Request/response characteristics (range 0–15).
•
SMP: Spontaneous message (not supported).
•
PNU: Parameter no. (range 1–1999).
5.3.3 Request/Response Handling
The RC portion of the PCA word defines:
•
The requests issued from the master to the slave.
•
Other portions of the PCV involved:
-
5 5
-
5.3.4 RC Content
Request
The content of the RC portion of the PCA word for a
request is listed in Table 5.15.
Request Function
0 No request.
1 Request parameter value.
2 Change parameter value (word).
3 Change parameter value (long word).
4 Request description element.
5 Change description element.
6 Request parameter value (array).
7 Change parameter value (array word).
8 Change parameter value (array long word).
9 Request number of array elements.
10–15 Not used.
Table 5.15 Request
Response
When the slave rejects a request from the master, the RC
word in the PPO read indicates the rejection by assuming
the value 7. Bytes 7 and 8 in the PVA element carry the
fault number.
The content of the RC portion of the PCA word for a
response is listed in Table 5.16.
30
PROFIBUS DP
PVA: The PVA portion transmits word-
size parameter values in bytes 7 and 8,
while long word size values require
bytes 5–8 (32 bits).
IND: When the response/request
contains array elements, the IND carries
the array subindex. When parameter
descriptions are involved, the IND holds
the record subindex of the parameter
description.
Danfoss A/S © 05/2016 All rights reserved.
Response Function
0 No response.
1 Transfer parameter value (word).
2 Transfer parameter value (long word).
3 Transfer description element.
4 Transfer parameter value (array word).
5 Transfer parameter value (array long word).
6 Transfer number of array elements.
7 Request rejected (including fault number, see
Table 5.17).
8 Not serviceable by PCV interface.
9 Not used.
10 Not used.
11 Not used.
12 Not used.
13–15 Not used.
Table 5.16 Response
Fault Interpretation
number
0 Illegal PNU.
1 Parameter value cannot be changed.
2 Upper or lower limit exceeded.
3 Subindex corrupted.
4 No array.
5 Data type false.
6 Cannot be set by user (reset only).
7 Description element cannot be changed.
8 IR required PPO write not available.
9 Description data not available.
10 Access group.
11 No parameter write access.
12 Key word missing.
13 Text in cyclic transmission not readable.
14 Name in cyclic transmission not readable.
15 Text array not available.
16 PPO write missing.
17 Request temporarily rejected.
18 Other fault.
19 Data in cyclic transmission not readable.
130 There is no bus access to the parameter called.
131 Data change is not possible because factory set-up is
selected.
Table 5.17 Fault Numbers
5.3.5 Example
This example shows:
•
How to use PPO type 1 to change the ramp-up
time to 10 s in parameter 3-41 Ramp 1 Ramp Up
Time.
•
How to command a start and speed reference of
50%.
MG07F102
