Illustration 4.1 Available PPO Types

4.2 Process Data

Use the process data part of the PPO to control and
monitor the frequency converter via the PROFIBUS.
4.2.1 Process Control Data
Process control data (PCD) is the process data sent from
the PLC to the frequency converter.
Master/slave
1 2
CTW MRV PCD
Table 4.1 Process Control Data
PCD 1 contains a 16-bit control word, and each bit controls
a specific function of the frequency converter. See
chapter 4.3 Control Profile.
PCD 2 contains a 16-bit speed setpoint in percentage
format. See chapter 4.2.3 Reference Handling.
MG07F102
Programming Guide
CTW/STW REF/MAV
CTW/STW REF/MAV
CTW/STW REF/MAV
CTW/STW REF/MAV
CTW/STW REF/MAV
CTW/STW REF/MAV
CTW/STW REF/MAV
CTW/STW REF/MAV
CTW/STW REF/MAV
3 ....... 10
....... PCD
PCD write
