Danfoss VLT Midi Drive FC 280 Programming Manual page 39

Parameters
8-53 Start Select
Option: Function:
Select the trigger for the start function.
[0] Digital A digital input triggers the start function.
input
[1] Bus A serial communication port or the fieldbus
triggers the start function.
[2] Logic AND The fieldbus/serial communication port and a
digital input trigger the start function.
[3] Logic OR The fieldbus/serial communication port or a
*
digital input triggers the start function.
8-54 Reversing Select
Option: Function:
Select the trigger for the reversing function.
[0] Digital A digital input triggers the reversing function.
input
[1] Bus A serial communication port or the fieldbus
triggers the reversing function.
[2] Logic AND The fieldbus/serial communication port and a
digital input trigger the reversing function.
[3] Logic OR The fieldbus/serial communication port or a
*
digital input trigger the reversing function.
8-55 Set-up Select
Option: Function:
Select the trigger for the set-up selection.
[0] Digital A digital input triggers the set-up selection.
input
[1] Bus A serial communication port or the fieldbus
triggers the set-up selection.
[2] Logic AND The fieldbus/serial communication port and a
digital input trigger the set-up selection.
[3] Logic OR The fieldbus/serial communication port or a
*
digital input triggers the set-up selection.
8-56 Preset Reference Select
Option: Function:
Select the trigger for the preset reference
selection.
[0] Digital A digital input triggers the preset reference
input selection.
[1] Bus A serial communication port or the fieldbus
triggers the preset reference selection.
[2] Logic AND The fieldbus/serial communication port and a
digital input trigger the preset reference
selection.
[3] Logic OR The fieldbus/serial communication port or a
*
digital input triggers the preset reference
selection.
MG07F102
Programming Guide
8-57 Profidrive OFF2 Select
Select control of the frequency converter OFF2 selection via the
terminals (digital input) and/or via the fieldbus. This parameter is
active only when 1parameter 8-01 Control Site is set to [0] Digital
and ctrl. word, and parameter 8-10 Control Word Profile is set to [1]
Profidrive profile.
Option:
[0]
[1]
[2]
[3]
*
8-58 Profidrive OFF3 Select
Select control of the frequency converter OFF3 selection via the
terminals (digital input) and/or via the fieldbus. This parameter is
active only when parameter 8-01 Control Site is set to [0] Digital
and ctrl. word, and parameter 8-10 Control Word Profile is set to [1]
Profidrive profile.
Option:
[0]
[1]
[2]
[3]
*
8-79 Protocol Firmware version
Range:
Size related
8-80 Bus Message Count
Range:
0 [0 - 4294967295] This parameter shows the number of valid
*
8-81 Bus Error Count
Range:
0 [0 - 4294967295] This parameter shows the number of
*
8-82 Slave Messages Rcvd
Range:
0 [0 - 4294967295] This parameter shows the number of valid
*
8-83 Slave Error Count
Range:
0 [0 - 4294967295] This parameter shows the number of error
*
Danfoss A/S © 05/2016 All rights reserved.
Function:
Digital input
Bus
Logic AND
Logic OR
Function:
Digital input
Bus
Logic AND
Logic OR
Function:
[0 - 65535 ] Firmware revision: FC is in index 0;
*
Modbus is in index 1; indexes 2–4
are reserved.
Function:
telegrams detected on the bus.
Function:
telegrams with faults (for example CRC
faults) detected on the bus.
Function:
telegrams sent by the frequency converter
to the slave.
Function:
telegrams, which could not be executed
by the frequency converter.
