1. INTRODUCTION

This manual covers basic AMP-O-LECTRIC Model "K" Terminating Machine 1-471273-3 and 1-471273-4
(shown in Figure 1), main accessories, and most common modifications.
MACHINE NUMBER
1-471273-3
1-471273-4
The machine is used to power the applicator that applies strip-fed terminals to wire. In addition, the machine is
also used as the principal component in other special application equipment covered in separate customer
manuals. These manuals refer to this one for basic machine information and parts.
Sections 1 through 9 provide a machine description and information on its installation, operation, maintenance,
troubleshooting, adjustment, repair, and parts replacement. Section 10 covers the accessories used to modify
the basic machine to a different configuration. When the accessories are factory installed, the machine part
number on the nameplate changes from the basic number to one identifying the modified configuration. Section
11 discusses these modified configurations by part number. The accessories are also available as kits for field
conversion, in which case the machine part number will no longer identify the configuration.
Rev Z
Figure 1
MACHINE DESCRIPTION
115 Vac, 60 Hz, and comes with Mechanical Feed Option 692140-2 factory installed
230 Vac, 50 Hz, and does NOT include Mechanical Feed Option 692140-2
409-5128
3 of 61
