TE Connectivity Basic AMP-O-LECTRIC K 1-471273-3 Customer's Manual page 26

ITEM PART NUMBER
- - - 1-471273-3
- - - 1-471273-4
1 20870-2
2 24195-1
3 23403-1
23709-1
4
23709-2
5 691400-7
6 691409-4
7 691400-8
8 691409-5
9 23430-3 •
10 640905-1
11 2-21002-5
453586-3
12
453586-5
13 3-21000-1
14 854586-1
15 21060-7
16 453866-1
Rev Z
DESCRIPTION
MACHINE ASSEMBLY, Basic Model "K" Machine (115V 60Hz)
MACHINE ASSEMBLY, Basic Model "K" Machine (230V 50Hz)
SWITCH, Toggle
PLATE, Switch
NUT, Speed
LIGHT, Indicator (115 Vac)
LIGHT, Indicator (230 Vac)
WIRE, Black, Terminated
WIRE, White, Terminated
WIRE, Black, Terminated
WIRE, White, Terminated
LIGHT, Work
TERMINAL, FASTON* .250 Series, Blue
SCREW, Btn Hd Skt Cap, 10-3 X 2.250 in. L
BOX ASSEMBLY, Trip Control (115 Vac)
BOX ASSEMBLY, Trip Control (230 Vac)
SCREW, Skt Hd Cap, 8-32 X 1.00 in. L
BARRIER STRIP, Modified
SCREW, Self-Tapping, 4-24 X .250 in. L
GUARD, Foot Switch
Figure 17 (Cont'd)
409-5128
QTY
- - -
- - -
1
1
1
1
1
1
1
1
1
1
2
2
1
1
2
1
2
1
26 of 61
