C. Replacement
There are no special procedures required for the replacement of parts in the air blast assemblies. Refer to the
exploded view and parts list for detail parts.
ITEM PART NUMBER
- - - 455350-1 •
- - - 455350-2 •
- - - 455350-3 •
1- 27319-4
2 22295-8
3 22309-2
4 22304-4
5 23054-1
6 22304-1
7 22306-2
8 22312-4
9 22306-1
10 3-21000-5
11 21899-2
12 21018-7
13 3-21000-6
14 23018-1
15 3-21000-4
16 811314-1
378393-
17
811210-1
18 452899-2
19 22306-3
• Recommended Spare Parts
Rev Z
BLAST ASSEMBLY, Air (For Applicator with Air Feed)
BLAST ASSEMBLY, Air (For Applicator with Mechanical Feed, .625 in. Max)
BLAST ASSEMBLY, Air (For Applicator with Mechanical Feed, .625 in. Min)
TUBING, Plastic, 1/4 in. Outside Diameter, 152 mm [6 in.] (Assembly -1)
FITTING, Male, 1/4 in. NPT X 1/4 in. Tube (Assembly -1)
TEE, Female Branch, 1/4 X 1/4 X 1/4 in. NPT (Assembly -1)
NIPPLE, Hex, 1/4 X 1/8 in. NPT (Assembly -1)
VALVE, Flow Control (Assembly -1)
NIPPLE, Hex, 1/8 in. NPT (Assembly -1)
ELBOW, Street, 1/4 in. NPT (Assemblies -2 and -3)
ADAPTER, 1/8 X 1/4 in. NPT (Assemblies -2 and -3)
ELBOW, Street, 1/8 in. NPT (Assembly -1)
SCREW, Skt Hd Cap, 10-32.50 in. L
WASHER, Flat, No. 10
NUT, Hex, 10-32
SCREW, Skt Hd Cap, 10-32 X .625 in. L
VALVE, On-Off
SCREW, Skt Hd Cap, 10-32 X .375 in. L (Assembly -2)
PLATE, Valve Mounting (Assembly -2)
ARM, Operating (Assemblies -1 and -3)
ARM, Operating (Assembly -2)
BRACKET, Mounting (Not Supplied with Assembly -1)
ELBOW, Street, 1/8 in. NPT (Assemblies -2 and -3)
Figure 31 (Cont'd)
DESCRIPTION
409-5128
QTY
- - -
- - -
- - -
1
2
1
1
1
1
1
1
1
2
2
1
1
1
2
1
1
1
1
1
