TE Connectivity Basic AMP-O-LECTRIC K 1-471273-3 Customer's Manual page 24

ITEM PART NUMBER
- - - 1-471273-3
- - - 1-471273-4
1 3-21001-7
2 371178
3 223141-3
4 3-21001-6
5 465004-1
6 373543
7 1-21007-5
8 370720
9 370719
10 370718
11 3-21002-4
12 21899-3
13 455740-1
14 2-21002-5
15 473391
16 21001-6
17 1-21007-0
18 23142-1
19 373535-
20 - - -
21 23201-1
22 21077-5
23 1-22202-4
Rev Z
DESCRIPTION
MACHINE ASSEMBLY, Basic Machine (115V 60Hz)
MACHINE ASSEMBLY, Basic Machine (230V 50Hz)
SCREW, Skt Hd Cap, 3/8-16 X 1.500 in. L
WASHER, Special
PLUG, Protective
SCREW, Skt Hd Cap, 3/8-16 X 1.250 in. L
PLATE, Ram Retaining
PIN, Toggle Link
SETSCREW, Skt Hd, 5/16-18 X .250 in. L
COLLAR, Adjusting Screw
SCREW, Adjustment
BLOCK, Adjustment
SCREW, Btn Hd Cap, 1/4-2 X 0.625 in. L
WASHER, Flat, 1/4 in.
BRACKET, Guard
SCREW, Btn Hd Cap, 10-32 X .250 in. L
COVER, Side Access
SCREW, Skt Hd Cap, 1/4-20 X 1.000 in. L
SETSCREW, Slflkg Skt, 1/4-2 X 1.000 in. L
FITTING, Straight Lubrication
PIN, Toggle Arm
TOGGLE LEVER-FEED ACTUATING COMPONENTS (See Figure 21 for
Breakdown)
FITTING, 90° Lubrication
SETSCREW, Sq Hd, 1/4-20 X 1.000 in. L
NUT, Hex 1/4-20
Figure 16 (Cont'd)
409-5128
QTY
- - -
- - -
2
2
1
4
1
1
1
1
1
1
1
1
1
2
1
6
1
1
1
1
1
1
1
24 of 61
