1. On-off switch (single-phase pumps only)
2. Lifting bracket (RV8 and RV12 pumps only; a
lifting handle is fitted to RV3 and RV5 pumps.)
* †
Pump
A A
RV3 430 429
RV5 430 429
RV8 470 469
RV12 490 489
*
Single-phase pumps.
†
Three-phase pumps.
© Edwards Limited 2018. All rights reserved.
Edwards and the Edwards logo are trade marks of Edwards Limited.
Figure 3 - Dimensions (mm)
B C D
158 225 127
158 225 127
158 225 161
158 225 181
A. Top view of single-phase pump
B. Side view of single-phase pump
C. Side view of three-phase pump
D. Front view of single-phase pump
E F G
29 78 230 120
29 78 230 120
35 78 230 120
35 78 230 120
A652–01–880 Issue Y
H I J
37 32
37 32
37 32 261
37 32 261
Page 13
K
–
–
