A652–01–880 Issue Y
2.6

Electrical data: single-phase pumps

Note: Edwards recommends using regional supply protection of the maximum ratings specified in
and Table 10. Protection of a higher rating must not be used.
The dual-voltage, dual-frequency motor is designed for a single-phase electrical supply and is suitable
for 50 Hz or 60 Hz operation. The motor can be manually switched between nominal supply voltages of 110–120 V
and 220-240 V (refer to Section
When a cold pump is started, the motor will draw the start-up current shown in
seconds. An appropriate rated and pre-approved time-lag fuse must be used to prevent unnecessary fuse failure
during pump start-up (in accordance with local and regional electrical codes). Within five minutes, as the oil in the
pump warms up, the current drawn will slowly reduce to the full load current specified in
Table 9 - Electrical data (single-phase pumps with Part Numbers ending in -903 or -906)
Pump
RV3, RV5, RV8 and
RV12
Table 10 - Electrical data (single-phase pumps with Part Numbers ending in -904)
Pump
RV3, RV5, RV8 and
RV12
2.6.1

Electrical cables

Recommended cord sets and fuses for regional requirements.
Page 14
3.6.1).
Nominal
Frequency
supply
(V)
220–240
230–240
110
115–120
Nominal
Frequency
supply
(V)
200
200–210
100
100–105
Table 11 - Recommended regional supply protection
Area Voltage (V)
UK
Europe
USA
Japan
Edwards and the Edwards logo are trade marks of Edwards Limited.
Table 9
Power
(Hz) (W)
50 450
60 550
50 450
60 550
Power
(Hz) (W)
50 450
60 550
50 450
60 550
Rating (A)
230 5
230 5
110 13
100 13
© Edwards Limited 2018. All rights reserved.
Table 9
and Table 10 for up to several
Table 9 and Table 10.
Full load
current
(A)
3.4
3.0
6.8
6.9
Full load
current
(A)
4.2
4.1
8.3
8.0
