Description
Cord set assembly, UK
Cord set assembly, Europe
Cord set assembly,
USA/Canada (200 - 230 V)
2.7

Electrical data: three-phase pumps

The dual-voltage, dual-frequency motor is designed for a three-phase electrical supply and is suitable for 50 Hz or
60 Hz operation. The motor can be manually configured for nominal supply voltages of 220–240 V or 380–460 V (refer
to Section 3.7.1). Pumps are supplied preset for nominal 380–460 V electrical supplies.
When a cold pump is started, the motor will draw the start-up current shown in
current will then reduce quickly as the motor reaches the rated rotational speed. Within 5 minutes, as the oil and
pump warms up, the current drawn will slowly reduce to a maximum of the full load current specified in
When a warm pump is started, the motor will draw the start-up current shown in
current drawn will then immediately fall to the full load current.
Electrical short-circuit and ground-fault protection of the pump will be provided by fitting appropriate pre-approved
branch circuit protector or Class CC fuses of the values shown in
Table 13 - Electrical data (three-phase pumps with Part Numbers ending in -905)
Nominal
Pump
RV3 and RV5 200–220
200–230
380–415
RV8 and RV12 200–208
200–230
380–415
*
Observe requirements of local and regional electrical codes with respect to supply protection.
© Edwards Limited 2018. All rights reserved.
Edwards and the Edwards logo are trade marks of Edwards Limited.
Table 12 - Recommended cord sets
Rating
Cable style = H05VV-F, 3 x 1.0 mm
70 °C, maximum length of 2.0 metres
Plug type = BS1363 UK plug
Appliance coupler = IEC60320 style C14
Fuse type = BS1363 10 Amp fuse, to an
IEC60320 style
Cable style = H05VV-F, 3 x 1.0 mm
70 °C, maximum length of 2.0 metres
Plug type = European Schuko VDE approved,
16 A 250 V rated with dual earthing contact
Appliance coupler = IEC60320 style C14
Cable style = SJT, 3 x 14 AWG, 300 V,
90 °C, VW-1 maximum length of 3.0 metres
Plug type = NEMA, 6-15P plug
Appliance coupler = IEC60320 style C14
Frequency
supply
(Hz)
(V)
50
60
50
460 60
50
60
50
460 60
Coupler type
2
, 300 V, Straight entry
2
, 300 V, Straight entry
Table 13
Table 13
Table 13 at the point of connection to the supply.
Full load
Power
current
(W)
(A)
250 1.7
300 1.7
250 1.0
300 1.0
450 2.5
550 2.9
450 1.5
550 1.5
A652–01–880 Issue Y
Item number
A50505000
A50506000
N/A
for up to 0.5 seconds. The
Table 13.
for up to 0.5 seconds. The
Recommended
Start-up
supply
current
(A)
protection (A)
10.2 2.5
10.2 2.5
5.7 2.5
7.0 2.5
14.0 4.0
12.0 4.0
9.0 2.5
8.7 2.5
Page 15
*
