Motor Voltage Configuration: Single-Phase Pumps - Edwards RV3 Instruction Manual

A652–01–880 Issue Y
A. Top view of motor
B. View of voltage selector switch cover
C. View of On-off switch
Page 20
Figure 4 - Motor voltage configuration: single-phase pumps
Edwards and the Edwards logo are trade marks of Edwards Limited.
1. Terminal box
2. Electrical inlet-connector
3. Voltage selector switch
4. On-off switch
5. Voltage selector switch cover
6. Retaining screws
7. Position 'I' (on)
8. Position '0' (off)
