1.2.2

Physical Description

Speaker
Call
button
Microphone
The front panel of the Pantel unit incorporates a speaker,
microphone, and Call button. The front panel is attached to the
wall using a bracket and screws.
The Pantel unit is a hardwired unit powered by an external
12V AC transformer, which is provided in the package.
Optionally, you may use a 12-24V DC adapter. (For outdoor
unit only.)
1.3

Pancode

The Pancode is a smart wall mounted access control door
phone that is connected to an analog port of a PBX or a Key
Telephone System, allowing door entry control.
The Pancode is available in either an aluminum unit for
outdoor installation, which is weather and vandal resistant, or
a plastic unit for indoor installation.
1.3.1

Features

The outdoor and indoor Pancode units have the following
features:
Direct dialing to any extension
Entry access code
Speed-dial to internal or external subscribers
Automatic Busy & Disconnect Cadence Detection
(outdoor unit only)
4 PanCam/Pantel/Pancode Installation and Programming Manual
Indoor Unit
Figure 1-2. Pantel Front Panel
Introduction
Outdoor Unit
