the proper terminal and tighten the terminal screw. This will
crimp the wire connection.
To avoid damage to the Pantel/Pancode, the power supply
should be turned off prior to connecting wires to the
Pantel/Pancode unit.
To Install the Pantel/Pancode
1.
Remove the cover from the Pantel/Pancode unit and
disconnect the wire connector, found at the base of the
internal component.
2.
Connect the two 12V lead wires from the 12V AC power
adapter (or the 12-24V DC adapter), one to each of the
"~12V" terminals.
3.
Connect the two PBX extension wires, one to each of the
"LINE" terminals.
4.
Connect the door-lock relay wires to the "DLR" and
"~DLR" terminals
-or-
If the door-lock relay is a powered-locked-state type
lock, connect the door-lock relay wires to the "/DLR"
and "~DLR" terminals.
5.
If a push button switch is used, connect the push button
wires to the "SW" and the "/SW" terminals.
6.
Plug the wire connector to the base of the
Pantel/Pancode inner component.
7.
Place the Pantel/Pancode onto the mounting bracket.
8.
Switch on the power to the 12V adapter.
After installation, you can now program the Pantel/Pancode
unit. For details on programming, see section 3, Programming.
2.2
Adjacent Access Control Device
This section describes adding an access-control device to an
existing Pantel/Pancode, and adding a Pantel/Pancode to an
existing access-control device. The key difference between
these two installations is which Access-control device controls
the door lock relay.
2.2.1
Adding an Access Control Device to the
Pantel/Pancode
When activated, the access-control triggers the Pantel/Pancode
"SW" terminal, which activates the door-lock relay and opens
the door.
PanCam/Pantel/Pancode Installation and Programming Manual
Caution
9
