2.
Physical Description
The Pancode VoIP and Pantel VoIP are attached to the wall using a bracket and screws. These units are
hardwired and powered by an external 12V AC transformer, included in the package. The Pancode VoIP and
Pantel VoIP dimensions are:
Height: – 19.4 cm
Width: – 10.2
Flush Mounted unit dimensions are:
Flush Panel:13.8 x 23.3cm / 5.4 x 0.9 inch
Flush Mounted part: 9.8 x 19 x 2.5 cm/3.8 x 7.5 x 0.9 inch
2.1
Pancode VoIP Front Panel
The front panel of the Pancode VoIP unit contains a built-in speaker, a microphone, touch-keypad and
internal video camera hole (optional) (Figure 2-1).
Pancode VoIP/Pantel VoIP Access Control Door Phones
Figure 2-1. Pancode VoIP Front Panel
Installation and Programming Manual
4
