Mechanical and environmental
Table 34: Mechanical
Dimensions (W x H x D)
Weight (including backplane)
Display module
Detector module
Number of cable knockouts
Top
Bottom
Back
Detector module orientation
IP rating
Display module
Detector module
Flammability rating
Dust filter replacement
Detector chamber maintenance
Table 35: Environmental
Operating temperature
Storage temperature
Relative humidity
ModuLaser Modular Aspirating Smoke Detector Installation Manual
Chapter 5: Technical specifications
110.5 mm x 300 mm x 133.5 mm
(4.35 in. x 11.81 in. x 5.25 in.)
1.18 kg (2.6 lb.)
1.57 kg (3.46 lb.)
3 x Ø 20.7 mm (0.815 in)
2 x Ø 20.7 mm (0.815 in)
2
Vertical or horizontal
IP40
IP40
UL94 V0
Timed warning integrated.
Subject to installation environment
−20ºC to +60ºC (0ºC to 38ºC UL268, cUL
and FM)
−20ºC to +60ºC
+5 to 95% noncondensing (0 to 90% for UL/cUL
and FM)
IEC 61010-1 Pollution degree 1
IEC 61010-1 Installation Cat. II
