Configuration options
The options listed below are available when making configuration changes.
Table 8: Configuration controls
Option Button
Save F1
Apply F1
Cancel F2
Exit F3
Notes
• Configuration changes are only applied to the system by pressing F1 (Apply).
• When updating multiple configuration settings, we recommend that you save
after each change, and then apply all changes from the Main menu.
• Only values within the allowed range for each parameter will be accepted.
• Any changes not applied are lost when the system exits a restricted user
level.

Wizards

Wizards are provided to assist maintenance and configuration tasks. Access
restrictions for each are shown below.
Wizard
Maintenance wizard
Configuration wizard
The maintenance wizard
To use the maintenance wizard:
1. Press F1 (Wizard) from the Main menu.
2. Select Maintenance Wizard.
3. Press F3 (Next) to step through the menus included in the wizard (see
Table 9 on page 40).
Press Enter to access a menu. From a menu, press F2 (Back) to return to the
wizard.
ModuLaser Modular Aspirating Smoke Detector Installation Manual
Description
Saves the current configuration change without applying it
immediately.
Note: When making configuration changes to legacy devices, the
changes are saved by pressing F1 (Apply).
Applies the current configuration change and all stored (saved)
configuration changes. The detector resets automatically.
Discards the current configuration change and returns to the previous
screen.
Exits the configuration process without storing or applying the current
configuration change. The configuration process can be resumed.
Access level
Access level 2 and higher
Access level 3 and higher
Chapter 3: Configuration and Commissioning
39
