Chapter 3: Configuration and Commissioning
Display module controls
Use the buttons on the front of the display module to navigate menus, to select
menu options, and to enter passwords and system information.
Figure 21: Display module controls
Table 7: Display module controls
Item
Button
1
Down
2
Left
3
Up
4
Right
5
Enter
6
F3
7
F2
8
F1
38
Description
Press to scroll down a menu or to decrease the value of a parameter
Press to scroll left or to navigate to the previous field or digit
Press to scroll up a menu or to increase the value of a parameter
Press to scroll right or to navigate to the next field or digit
Press to confirm a selection or value
Soft key – functionality changes depending on menu (Menu, Logout,
Exit, etc.)
Soft key – functionality changes depending on menu (Menu, Logout,
Exit, etc.)
Soft key – functionality changes depending on menu (Menu, Logout,
Exit, etc.)
ModuLaser Modular Aspirating Smoke Detector Installation Manual
