Icon
Detection aborted
FastLearn mode
Intermediate learn
mode
Normal mode
Flow setup
Pipe calibration
Day mode
Night mode
Table 12: Status screen values
Value
Alarm 2
Alarm
Prealm
Alert
Dlevel
Filter
Flow
FH Lim
FL Lim
Fan Spd
Table 13: Status screen banner messages
Banner message
Detection Aborted
Alarm 2 [2]
Alarm [2]
Prealarm [2]
Alert [2]
ModuLaser Modular Aspirating Smoke Detector Installation Manual
Description
Indicates that the detection is aborted.
Indicates that the detector is in FastLearn mode. This mode is
used to learn the current smoke level present in the
environment.
Indicates that the detector is in intermediate learn mode. In this
mode, the detector is partially operational while it is fine tuning
the environment learning.
Indicates that the detector mode of operation is normal.
Indicates that flow setup is in process.
Indicates that pipe calibration is in process.
Indicates that the primary sensitivity mode setting for the
detector is day mode.
Indicates that the primary sensitivity mode setting for the
detector is night mode.
Description
The Fire Alarm 2 smoke threshold (percentage)
The Fire Alarm smoke threshold (percentage)
The Prealarm smoke alarm threshold (percentage)
The Alert/Aux. Alarm smoke threshold (percentage)
The detector output level (percentage)
The filter cleanliness level (percentage)
The flow measured for the detector (lpm or cfm)
The flow high limit (lpm or cfm)
The flow low limit (lpm or cfm)
The fan speed (1 to 16)
Displays
Displays when detection is aborted
Displays during a Fire Alarm 2 state
Displays during a Fire Alarm state
Displays during a Prealarm state
Displays during an Alert/Aux. Alarm state
Chapter 3: Configuration and Commissioning
Priority [1]
1
2
3
4
5
