To configure inputs:
1. Select Device Settings from the Main menu, and then select Inputs.
2. Select the device that you want to view or press F1 (Go To) to search for a
device by the device address.
3. Select the input that you want configure, and then configure the Influence and
Function fields as required.
See Table 20 below for more information on input functionality.
4. Press F1 (Save) to save your changes and exit to the previous screen.
5. If you have no other configuration changes to make, then press F1 (Apply)
from the Main menu or the submenu to apply the changes to the system.
The configurable options for the input functionality are shown in the table below.
All inputs can be configured for Local or Cluster influence.
Table 20: Input functionality
Function
Unused
Battery Check
Mains Check
Remote Reset
Remote Disable
Rem. Day/Night [1]
[1] Only available for detector modules.
Notes
• When a function is enabled for a given input, any previous configuration using
that input is automatically disabled.
• An open circuit in an input will be indicated as an Input Open Circuit fault.
• Avoid configuring two or more inputs with the same functionality (this may
create conflicts).
• Inputs and input functionality for legacy devices may vary from those
described here. Refer to the corresponding device installation manual for
more information.
ModuLaser Modular Aspirating Smoke Detector Installation Manual
Description
The input is not used (this is the default setting).
When the input deactivates, the module generates a fault condition
(battery fault).
When the input deactivates, the module generates a fault condition
(mains voltage fault). The device or devices affected by the
configured influence enter power save mode (if configured to do so).
When the input activates, the device or devices affected by the
configured influence are reset.
When the input activates, the device or devices affected by the
configured influence are disabled.
Remote Day/Night. When the input activates, the device or devices
affected by the configured influence are set to day mode. When the
input is deactivated, they are set to night mode.
