Chapter 3: Configuration and Commissioning
Banner message
Pipe calibration in progress
Retrieving flow data, please
wait....
FastLearn Rem. Time: X
mins
Intermediate Learn
Normal Mode
[1] When multiple events are active, the messages with the higher priority are displayed.
[2] Alarm states display as flashing red text.

The Main menu

The Main menu for this access level is shown below.
Figure 23: Access level 2 Main menu

The General Settings menu

Use the General Settings menu to localize the display and to change screen
display properties.
Localizing the display
Use the Localize menu to localize the display, such as the language and
measurement unit used. Configurable options are shown in the table below.
Table 14: Localization options
Option
Language
Units
Date Format
44
Displays
Displays during pipe calibration
Displays during flow setup
Displays during FastLearn
Displays during intermediate learning
Displays when in normal mode
Description
Configures the language of the display, and log files.
Configures the measurement unit system (metric or imperial).
Configures the date format (DD/MM/YY or MM/DD/YY).
ModuLaser Modular Aspirating Smoke Detector Installation Manual
Priority [1]
6
7
8
9
10
